LOCATION REQUIREMENTS

WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
IMPORTANT : This refrigerator is designed for indoor,
household use only.
This appliance is intended to be used in household and
similar applications such as:
Staff kitchen areas in shops, offices and other working
environments.
Farm houses and by clients in hotels, motels and
other residential type environments.
Bed and breakfast type environments.
Catering and similar non-retail applications.
NOTE : The refrigerator is intended for use in a location
where the temperature ranges from a minimum of
55°F (13°C) to a maximum of 110°F (43°C). The preferred
room temperature range for optimum performance,
which reduces electricity usage and provides superior
cooling, is between 60°F (15°C) and 90°F (32°C). It is
recommended that you do not install the refrigerator
near a heat source, such as an oven or radiator.
Observe all governing codes and ordinances.
It is recommended that you do not install the
refrigerator near an oven, radiator, or other heat
source.
Do not install in a location where the temperature will
fall below 55°F (13°C).
Floor must support the refrigerator weight, more
than 600 lbs (272 kg), door panels and contents of
the refrigerator. Flooring under refrigerator must be
at same level as the room. Face of cabinetry must be
plumb.
Location should permit door to open fully. See "Door
Swing Dimensions."
Location must permit top grille removal. See
"Opening Dimensions."
OPENING DIMENSIONS
IMPORTANT :
The width of the opening (Width A), from side to side,
must be as specified for your model for at least
2" (5.08 cm) back from the face of the cabinet.
NOTE : If your opening does not meet this requirement,
you will need to make modifications.
A solid soffit or wall cabinet must be installed
84" (213.4 cm) above the floor. If the solid soffit is
higher than 84" (213.4 cm) or one is not available, then
the refrigerator must be braced.
If anti-tip boards are needed, they must be installed
to the rear wall studs so that the bottom of the
anti-tip board is 84" (213.4 cm) from the floor. See
"Install Anti-Tip Boards" for more information.
NOTES :
Do not remove the foam gasket from the top of the
compressor cover unless removal is necessary to fit
the unit under a soffit. Removal of the gasket will
cause loss in cooling efficiency.
If installing under a solid soffit, after installation raise
the leveling legs so that the gasket is pressed snugly
against the soffit.
A
B
A. Gasket
B. Compressor cover
A grounded 3 prong electrical outlet should be
located within a specified number of inches from
the right-hand side cabinets or end panel. See the
chart following the graphic for the number of inches
required for your model. For more information, see
"Electrical Requirements."
