4.2.3.
Testing TELNET Server
1.
Supply the power to W5300E01-ARM board and check booting.
2.
Execute TELNET Client program.
Windows : Start -> 'Run' -> Input 'telnet'
Linux : Input 'telnet' at the terminal
3.
Log in with 'id > wiznet, password > wiznet'.
4.2.4.
Testing Loopback
With the loopback program in W5300E01-ARM, it is possible to test both of S/W & H/W TCP/IP stack.
Loopback program is installed in '/root' directory of 5300E01-ARM board.
1.
Install AX1 provided by CD. (Software/Tools/AXInstallV3.1.exe)
For the detail of AX1, refer to 'Documents/Menual/AX1 Menual V3.1' provided by CD.
2.
Supply the power to W5300E01-ARM and check booting.
3.
Log in with 'root'.
4.
Execute the Loopback server with './loopback –t -w' command. The option of Loopback is as below.
-h
Looback help
-u
UDP loopback mode
-t
TCP loopback mode
-w
PF_WIZNET(H/W TCP/IP) loopback mode(Default 'PF_INET')
-b <size>
Buffer size(Default 4096)
-p <port>
Port number(Default 5001)
Figure 4-7 : TELNET Server Test
Table 4-1 : Loopback Option
© Copyright 2008 WIZnet Co., Inc. All rights reserved.
22
