WIZ610WI Quick Installation Guide
(Version 1.0)
©2008 WIZnet Co., Inc. All Rights Reserved.
☞ For more
information, please visit our website
at
http://www.wiznet.co.kr
WIZnet's Online Technical Support
If you have
any questions about our products, please visit our website and post your questions
on the Q&A Board. We will reply your questions as soon as possible
Advertisement
Related Manuals for Wiznet WIZ610WI
Summary of Contents for Wiznet WIZ610WI
- Page 1 WIZ610WI Quick Installation Guide (Version 1.0) ©2008 WIZnet Co., Inc. All Rights Reserved. ☞ For more information, please visit our website http://www.wiznet.co.kr WIZnet’s Online Technical Support If you have any questions about our products, please visit our website and post your questions...
-
Page 3: Copyright Notice
COPYRIGHT NOTICE Copyright 2008 WIZnet, Inc. All Rights Reserved. Technical Support: support@wiznet.co.kr Sales & Distribution: sales@wiznet.co.kr For more information, visit our website at http://www.wiznet.co.kr... -
Page 4: Hardware Setting
You can use any types of UTP cable (direct or crossover cable). Step 2. Connecting Serial Cable Connect WIZ610Wi evaluation board to your PC by using the DB9 female serial cable. Step 3. Connecting Wireless LAN Antenna 메모 [q1]: Full name of this Connect the wireless LAN antenna to the U.FL connector of WIZ610wi. -
Page 5: Wireless Setting
AP Mode : If there is another DHCP server operating at the upper level in the network, it assigns IP address to the client, but does not to WIZ610Wi. If there is not any other 메모 [q5]: Don’t use DHCP server, WIZ610Wi assigns IP address. - Page 6 / WDS Setting SSID: SSID should be configured for the wireless communication. The default SSID is “WIZ610Wi”. You can rename your SSID to a name of your choice Channel: A different channel should be selected when your device experienced interferences from other wireless network. The default channel is set as “1”.
- Page 7 Mode : Select a mode (Server, Client, Mixed) Server IP/Port : At the Client or Mixed mode, you should set the server IP address. WIZ610Wi will try to connect to this server IP address. Configure Baud rate, Databits, Parity, Stopbits, Flow Control.
- Page 8 Connect to “WIZ610Wi” in the Wireless Network Setting of your PC Open another Terminal program and input IP address and Port Number of WIZ610Wi.
- Page 9 Input any characters in the Hyper Terminal for Serial. (In the example below, “01234567890” is input). The same characters are outputted in the Hyper Terminal for Network. A Serial to Wireless LAN test was performed. Received Data by Network Terminal Program...
- Page 10 TCP Server modes at the same time. If the Server Mode is enabled, Device Terminal will operate as server mode, and the WIZ610Wi module will work as client mode. The PC where the Device Terminal is operating will work as a server, the IP address of the PC should be set as Server IP of the module. If 메모...
- Page 11 When serial and network terminals are connected, input any character in the Data Input window and click “Send” button. You can check the data is transferred into thes another window.
