1. What is AX1
AX1 Program is a Windows-based PC Program in order to evaluate the performance
of iinChip™, WIZnet's Hardwired TCP/IP Chip.
AX1 is connected with iinChip™ Evaluation Board(EVB B/D) and TCP/IP Protocol
through Internet. First of all, connected Internet TCP/IP Protocol transmits optional
Packet or Files to iinChip™™ EVB B/D. Secondly, it checks the meeting point between
returned Packet or Files from TCP/IP Protocol and transmitted Packet or Files. Finally,
it measures the transmission and the reception speed
AX1's functions are like below.
TCP Protocol Test
UDP Protocol Test
2. Installation
You can install AX1 through Software CD included in iinChip™ EVB B/D Product
Package or WIZnet 's homepage (http://www.wiznet.co.kr)
AX1 Program installation process is like below.
○
1 Execute "AXInstallVX.X.exe"
'VX.X' of the file name means the Version of AX1 Program. Until now, the latest
version is 3.1. You can get the latest version from WIZnet's homepage.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Wiznet AX1
Summary of Contents for Wiznet AX1
- Page 1 Package or WIZnet ‘s homepage (http://www.wiznet.co.kr) AX1 Program installation process is like below. ○ 1 Execute “AXInstallVX.X.exe” ‘VX.X’ of the file name means the Version of AX1 Program. Until now, the latest version is 3.1. You can get the latest version from WIZnet’s homepage.
- Page 2 <Fig 2.1> AX1 install Program’s execution ○ 2 Appoint Directory for the install of AX1 Program <Fig 2.2> AX1 Program 설치 Directory 지정 ○ 3 Select registered name in “Program Manger Group”...
- Page 3 <Fig 2.3> Select Program Manager Group ○ 4 If you finish preparations for AX1 Program installation, start installation. <Fig 2.4> Start installation ○ 5 AX1 Program’s installation complete...
- Page 4 <Fig 2.5> AX1 Program’s installation complete 3. How to use 3.1. System Configuration Let’s look around Test PC installed AX1 Program and system composition of iinChip™ EVB B/D. Test interface consists of two types like below. LAN (Local Area Network) interface WAN (Wide Area Network) interface First of all, LAN interface is build up in the same Segment Network.
- Page 5 Cross UTP Cable iinChip EVB B/D Test PC Direct UTP Cable Test PC iinChip EVB B/D <Fig 3.1> System composition example in LAN interface The same Segment Network in LAN means the Network information between Test PC and iinChip™ EVB B/D is same. That is to say, if Source IP Address of iinChip™ EVB B/D is ‘192.168.0.2’, Gateway IP Address is ‘192.168.0.1’...
- Page 6 3.2. How to Test If Test environment is composed, execute AX1 Program in Test PC. <Fig 3.3>is AX1 Program execution window <Fig 3.3> AX1 Program execution Refer to <Table 3.1> and <Table 3.2> for understanding AX1 Program’s various functions.
- Page 7 File Loopback User appointed times through connected TCP Channel File Loopback User appointed times through opened UDP Channel ∞ File Loopback repeat infinitely through TCP or UDP Channel ∅ Stop Loopback repeat test <Table 3.2> AX1 Program Tool Icons description...
- Page 8 3.2.1. TCP Server Test TCP Server is working like below. AX1 Program: TCP Loopback Server iinChip™ EVB B/D: TCP Loopback Client ○ 1 Click Menu [TCP > Listen] <Fig 3.4> TCP Server Listen ○ 2 Select Waiting Server Listen Port <Fig 3.5>...
- Page 9 ○ 6 Packet or File Loopback through connected TCP Channel 3.2.1.1. TCP Packet Loopback Random Packet Loopback one time to iinChip™ EVB B/D through connected TCP Channel. ○ 1 Click Menu [TCP > Send] <Fig 3.7> TCP Packet Loopback ○ 2 Create TCP Packet’s Size and Value <Fig 3.8>...
- Page 10 3.2.1.2. TCP File Loop-back Random File Loopback to iinChip™ EVB B/D through connected TCP Channel ○ 1 Click Menu [File > Open] and Open Loopback File <Fig 3.10> TCP Loopback File Open ○ 2 Click a Tool Icon of [Ts], [T ], and [∞].
- Page 11 3.2.2. TCP Client Test TCP Client is working like below. AX1 Program: TCP Loopback Client iinChip™ EVB B/D: TCP Loopback Server ○ 1 Operate iinChip™ EVB B/D in TCP Loopback Server Refer to iinChip™ EVB Manual for iinChip™ EVB B/D operating setting ○...
- Page 12 1 Click Menu [UDP > Open] <Fig 3.17> UDP Channel Open ○ 2 Appoint UDP Source Port which will be used in AX1 Program <Fig 3.18> UDP Source Port Setting If you want to use random Source Port, appoint the Port Number as 0(Zero) If you do not appoint specific Source Port for UDP Channel and you use random ○...
- Page 13 3.2.3.1. UDP Packet Loopback Packet Loopback infinitely to iinChip™ EVB B/D through UDP Channel ○ 1 Click Menu [UDP > Send] <Fig 3.19> UDP Packet Loopback ○ 2 Select EVB B/D’s IP Address and Port for Loopback Appoint UDP Packet’s Size and Value <Fig 3.20>...
- Page 14 It is a separate issue and irrelevant to reception success or not. Otherwise, UDP Loopback File Test does not guarantee Data Flow Control. Therefore, before completion of sending File Data that iinChip™ EVB B/D received to AX1 (i.e. until completion of File Data Loopback), the next File Data cannot be transmitted.
- Page 15 ○ 3 iinChip™ EVB B/D’s IP Address and UDP Port Setting for Loopback <Fig 3.24> iinChip™ EVB B/D’s IP and Port Setting for UDP Loopback Test ○ 4 UDP File Loopback Test <Fig 3.25> UDP File Loopback Test execution...
