  • Page 1 PinCode Keypad Manual 14.05.2019...

  • Page 2: Table Of Contents

    Contents PinCode Keypad (Manual) 2 / 28 Contents General information .......................... 3 Intended use...............................  3 Safety instructions............................ 4 How it works .............................. 5 Overview................................ 5 Operating modes .............................  5 Operation ................................ 6 2.3.1 Opening.............................. 7 Initial operation............................ 8 PINs ................................ 9 Changing of the Master PIN ........................ 9 Programming PINs ............................

  • Page 3: General Information

    1. General information PinCode Keypad (Manual) 3 / 28 1 General information 1.1 Intended use The PIN code keypad can be used to activate SimonsVoss locking devices such as locking cylinders, SmartHandles or SmartRelays, by entering a numerical code. The PIN code keypad is integrated into the locking system using the corresponding locking system software.

  • Page 4: Safety Instructions

    1. General information PinCode Keypad (Manual) 4 / 28 1.2 Safety instructions The batteries used may pose a fire or burn hazard if handled incorrectly.  Do not recharge, open, heat or burn these batteries. Do not short-circuit! Dispose of old or used batteries correctly. Store out of children's reach.

  • Page 5: How It Works

    2. How it works PinCode Keypad (Manual) 5 / 28 2 How it works The PIN code keypad is a digital key that opens SimonsVoss locking devices via radio once the correct PINs have been entered. The PIN code keypad uses one of the three integrated transponders for this purpose.

  • Page 6: Operation

    2. How it works PinCode Keypad (Manual) 6 / 28 Status Explanation Sleep mode. The PIN code keypad Standby consumes very little energy. Active mode. The PIN code keypad checks the input and, if the input is Opening correct, actuates the locking device...
  • Page 7 2. How it works PinCode Keypad (Manual) 7 / 28 2.3.1 Opening You open the locking device to which the integrated transponder has been assigned as follows: ü At least one PIN programmed. At least one integrated transponder assigned to the locking device.

  • Page 8: Initial Operation

    3. Initial operation PinCode Keypad (Manual) 8 / 28 3 Initial operation Initial operation is performed in three steps. 1. Change the master PIN (see Changing of the Master PIN [  9] Programming PINs [  10] 2. Programme one or more PINs (see 3.

  • Page 9: Pins

    4. PINs PinCode Keypad (Manual) 9 / 28 4 PINs The PIN code keypad distinguishes between one Master PIN and up to three User PINs. With the Master PIN it is possible to make changes to the programming of the PIN code keypad, with the User PINs it is possible to operate the assigned locking device.

  • Page 10: Programming Pins

    4. PINs PinCode Keypad (Manual) 10 / 28 2. Enter the old Master PIN (factory setting: 12345678). 3. Enter the new Master PIN. IMPORTANT Requirements for the Master PIN The Master PIN must be secure. It must therefore meet the following re- quirements.

  • Page 11: Deleting Pins

    4. PINs PinCode Keypad (Manual) 11 / 28 IMPORTANT Requirements for the User PIN The User PIN must be secure. It must therefore meet the following require- ments: 1. The User PIN must consist of four to eight characters. 2. The digits of the User PIN must not be consecutive.
  • Page 12 4. PINs PinCode Keypad (Manual) 12 / 28 Deleted User PINs can no longer be used to operate the locking device. If you do not want to use all User PINss, leave them unprogrammed. Enter 0 Enter the master PIN...

  • Page 13: Transponder

    5. Transponder PinCode Keypad (Manual) 13 / 28 5 Transponder Each User PIN is assigned to one of the three integrated transponders. If you want to use and differentiate between the different User PINs, you must programme the integrated transponders individually (see Programming the transponders [  13]...
  • Page 14 5. Transponder PinCode Keypad (Manual) 14 / 28 IMPORTANT No access due to incorrect assignment If you do not observe the assignment, a user may not be able to use their User PIN. 1. When programming, select the correct number of the corresponding User PIN! 2.

  • Page 15: Reading Out The Transponders

    5. Transponder PinCode Keypad (Manual) 15 / 28 "Programming successful" window is displayed. User PIN was linked to the entry in the matrix. Repeat the programming for all other User PINs that you want to assign. If you do not want to use all User PINss, leave them unprogrammed.

  • Page 16: Resetting Transponders

    5. Transponder PinCode Keypad (Manual) 16 / 28 The window "Read transponder data" opens. Open the readout menu (LSM software: "Read out transponder") Enter user PIN (is read out) 5.3 Resetting transponders You can reset the integrated transponders at any time using the LSM software.
  • Page 17 5. Transponder PinCode Keypad (Manual) 17 / 28 Reading transponders Enter the master PIN Enter the master PIN Start reset (LSM software: “Reset”) Enter the master PIN Enter 1,2 or 3 (Number of the transponder)

  • Page 18: Signal

    6. Signal PinCode Keypad (Manual) 18 / 28 6 Signal LED flashing beeper Meaning Cause You have entered a 1 x green, short 1× Number entry number. You have entered a Transponder, active correct PIN. You have success- Programming suc-...
  • Page 19 6. Signal PinCode Keypad (Manual) 19 / 28 LED flashing beeper Meaning Cause The batteries PIN code keypad are very low. The PIN code keypad oper- ates the locking device only after a delay of twenty seconds. Change the batteries immedi-...

  • Page 20: Battery Replacement

    7. Battery replacement PinCode Keypad (Manual) 20 / 28 7 Battery replacement To change the batteries, you must open the housing of the PIN code keypad. For this you need a Torx screwdriver size 6 (not included in delivery)! ATTENTION Damage to the electronics due to fluids or static discharge Do not touch electronics/components;...
  • Page 21 7. Battery replacement PinCode Keypad (Manual) 21 / 28 7. Carefully hook the battery clips back into the circuit board. 8. Replace the front of the housing. 9. Screw the two screws back in the bottom of the housing completely.

  • Page 22: Special Functions

    8. Special functions PinCode Keypad (Manual) 22 / 28 8 Special functions 8.1 Double-click simulation (block lock operation on block lock 3066) You can use the PIN code keypad for activating SimonsVoss activation units (VdS block lock 3066). If a correct PIN has been entered, the activation unit is addressed.

  • Page 23: Other Information

    8. Special functions PinCode Keypad (Manual) 23 / 28 IMPORTANT Battery warning locks programming If one of the two battery warning levels is active, the programming cannot be changed. 1. Replace the batteries (see Battery replacement [  20] 2. Change the programming as required.

  • Page 24: Technical Specifications

    9. Technical specifications PinCode Keypad (Manual) 24 / 28 9 Technical specifications Dimensions 96 mm × 96 mm × 14 mm 2× CR 2032 (3V) Batteries: Always replace all batteries with new, approved, brand-name batteries when changing them. Sony ...

  • Page 25: Declaration Of Conformity

    10. Declaration of conformity PinCode Keypad (Manual) 25 / 28 10 Declaration of conformity The company SimonsVoss Technologies GmbH hereby declares that article TRA.PINCODE complies with the following guidelines: 2014/53/EU "Radio equipment"  2014/30/EU "EMC"  2011/65/EU "RoHS"  2012/19/EU "WEEE"...

  • Page 26: Help And Other Information

    11. Help and other information PinCode Keypad (Manual) 26 / 28 11 Help and other information Information material/documents You will find detailed information on operation and configuration and other documents under Informative material/Documents in the Download https://www.simons-voss.com/en/ section on the SimonsVoss website ( downloads/documents.html...
  • Page 27 11. Help and other information PinCode Keypad (Manual) 27 / 28 SimonsVoss Technologies GmbH Feringastrasse 4 85774 Unterföhring Germany...
  • Page 28 This is SimonsVoss SimonsVoss is a technology leader in digital locking systems. The pioneer in wirelessly controlled, cable-free locking technology delivers system solutions with an extensive product range for SOHOs, SMEs, major companies and public institutions. SimonsVoss locking systems unite intelligent functions, optimum quality and award-winning German-made design.
