PinCode Keypad (Manual)
IMPORTANT
No access due to incorrect assignment
If you do not observe the assignment, a user may not be able to use their
User PIN.
1. When programming, select the correct number of the corresponding
User PIN!
2. Check the assignment after programming by activating a locking device
(see Opening [ 7]
}
Create entry for the User PIN
1. In the LSM software (same locking plan), click on the button New
transponder .
The window "New transponder" opens.
9
2. In the dropdown menu Type select the entry "G1 Pin code".
3. Click on the OK button.
Window closes.
9
The entry for User PIN is created.
9
Repeat these steps for all other User PINs that you want to create.
Programming PIN code keypad
1. Select the User PIN entry in the matrix.
2. Open the context menu by right-clicking on the entry of the User PIN in
the matrix.
3. Select the context menu entry
The window "Transponder Programming" opens.
9
4. Enter the number sequence 00.
5. Enter the Master PIN.
6. Click on the Programming button.
7. Enter the number of the User PIN (for example, 1 for User PIN no. 1).
IMPORTANT
Radio error
If you hold the transponder too close to the programming device or activ-
ate the transponder too early, the radio link cannot be established.
1. Keep a distance of about 20 cm!
2. Do not activate the transponder until you are prompted in the LSM
software to press the transponder button.
Programming is performed.
9
9 PIN code keypad beeps and flashes green twice.
).
Programming
5. Transponder
14 / 28
.
