PinCode keypad AX
Manual
28.11.2024

Advertisement

loading
Need help?

Need help?

Do you have a question about the PinCode AX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Simons Voss Technologies PinCode AX

Summary of Contents for Simons Voss Technologies PinCode AX

  • Page 1 PinCode keypad AX Manual 28.11.2024...

  • Page 2: Table Of Contents

    PINs ................................ 9 Initial operation ............................ 10 Fastening.............................. 17 Fastening with glue pad .......................... 17 Fastening with screws.......................... 17 Battery replacement.......................... 20 Updating the PinCode AX firmware .................... 23 Reset ................................ 24 10. Feedback signals .............................  27 Technical data ............................ 28 11.1 Scale drawing.............................. 29 11.2...

  • Page 3: General Safety Instructions

    1. General safety instructions PinCode keypad AX (Manual) 3 / 34 1. General safety instructions Signal word: Possible immediate effects of non-compliance WARNING: Death or serious injury (possible, but unlikely) CAUTION: Minor injury IMPORTANT: Property damage or malfunction NOTE: Low or none WARNING Blocked access Access through a door may stay blocked due to incorrectly fitted and/or in-...
  • Page 4 1. General safety instructions PinCode keypad AX (Manual) 4 / 34 IMPORTANT Damage resulting from electrostatic discharge (ESD) when enclosure is open This product contains electronic components that may be damaged by electrostatic discharges. 1. Use ESD-compliant working materials (e.g. Grounding strap). 2.
  • Page 5 1. General safety instructions PinCode keypad AX (Manual) 5 / 34 NOTE Intended use SimonsVoss-products are designed exclusively for opening and closing doors and similar objects. Do not use SimonsVoss products for any other purposes.  Malfunctions due to poor contact or different discharge Contact surfaces that are too small/contaminated or different discharged batteries can lead to malfunctions.

  • Page 6: General Information

    2. General information PinCode keypad AX (Manual) 6 / 34 2. General information 2.1 Intended use You can use PIN code keypad AX to activate corresponding SimonsVoss AX locking devices by entering a numerical code (PIN), e.g.: SmartHandle AX  SmartHandle AX Advanced ...

  • Page 7: How It Works

    3. How it works PinCode keypad AX (Manual) 7 / 34 3. How it works The PIN code keypad AX is a digital key which opens suitable SimonsVoss locking devices after entering correct PINs via Bluetooth Low Energy (BLE). To do so, you can use the AXM for tasks related to the PIN code keypad AX: Create ...
  • Page 8 3. How it works PinCode keypad AX (Manual) 8 / 34 Initial ü PIN code keypad AX is authorised for just one locking device (see operation [  10] Initial operation [  10] ü PIN code keypad AX is programmed (see 1.

  • Page 9: Pins

    4. PINs PinCode keypad AX (Manual) 9 / 34 4. PINs A personal identification number (= PIN) is a numerical code that the PIN code keypad AX uses to identify a user as authorised. PINs for the PIN code keypad AX may only be Initial operation [  10] Created (see...

  • Page 10: Initial Operation

    5. Initial operation PinCode keypad AX (Manual) 10 / 34 5. Initial operation Initial operation is described as an example for the AXM in this section. Create PIN code keypad AX Locking device has been created for the PIN code keypad (see Creating ü...
  • Page 11 5. Initial operation PinCode keypad AX (Manual) 11 / 34 5. If you are creating a PIN code keypad AX, select the length of the PINs from the ▼ Pin length drop-down menu. 6. Enter the name to be displayed in the matrix for this PIN in the Pin name field.
  • Page 12 5. Initial operation PinCode keypad AX (Manual) 12 / 34 12. Select the time group you want to use for this PIN from the ▼ Time group drop-down menu. 13. If necessary, click the Add button to create additional PINs. 14.
  • Page 13 5. Initial operation PinCode keypad AX (Manual) 13 / 34 The highlighted hashtags in the left-hand column are used for this PIN code. 18. Select the Create additional objects checkbox to leave the window with the same settings open for the next PIN code to be created. 19.
  • Page 14 5. Initial operation PinCode keypad AX (Manual) 14 / 34 Synchronise PIN code keypad AX ü PIN code keypad AX created and assigned (see Creating PIN code keypads). ü Programming requirement for PIN code keypad AX, e.g. due to a change in authorisation.
  • Page 15 5. Initial operation PinCode keypad AX (Manual) 15 / 34 2. Press and hold the “0” button on the PIN code keypad AX for at least two seconds. 3. Position the SmartStick AX close to the PIN code keypad AX (max. 1 m). LED flickers green and PIN code keypad AX beeps.
  • Page 16 5. Initial operation PinCode keypad AX (Manual) 16 / 34 NOTE PIN code keypad AX in programming mode after synchronisation After synchronisation is complete, the PIN code keypad AX will not function for about 30 seconds as it is still in programming mode.

  • Page 17: Fastening

    6. Fastening PinCode keypad AX (Manual) 17 / 34 6. Fastening 1. Before fastening, test to ensure that your PIN code keypad AX reaches the locking device (range varies depending on locking device, see Tech- nical data [  28] 2. Allow the space required to insert a screwdriver so that the housing can be opened again at a later point in time.
  • Page 18 6. Fastening PinCode keypad AX (Manual) 18 / 34 2. Remove the keypad. 3. Align the base plate at the fastening point. 4. Screw/anchor the base plate firmly into position. 5. Put the housing keypad back into position.
  • Page 19 6. Fastening PinCode keypad AX (Manual) 19 / 34 6. Screw the keypad back onto the base plate. PIN code keypad AX is mounted.

  • Page 20: Battery Replacement

    7. Battery replacement PinCode keypad AX (Manual) 20 / 34 7. Battery replacement IMPORTANT Damage to the electronics due to fluids or static discharge Do not touch electronics/components; do not allow them to come into contact with oil, paint, moisture, alkali or acids. NOTE Shorter battery life due to poor contact Skin oil impairs contact between the battery and the battery holder.
  • Page 21 7. Battery replacement PinCode keypad AX (Manual) 21 / 34 2. Remove the keypad. 3. Remove the two batteries.
  • Page 22 7. Battery replacement PinCode keypad AX (Manual) 22 / 34 4. Insert two new batteries (CR2450) with the positive terminal facing up- wards. 5. Put the housing keypad back into position. 6. Screw the keypad back onto the base plate. The PIN code keypad AX’s batteries have been replaced.

  • Page 23: Updating The Pincode Ax Firmware

    8. Updating the PinCode AX firmware PinCode keypad AX (Manual) 23 / 34 8. Updating the PinCode AX firmware You can update the firmware for your PIN code keypad AX yourself using the AX firmware updatetool and a SmartStick AX.

  • Page 24: Reset

    9. Reset PinCode keypad AX (Manual) 24 / 34 9. Reset Resetting is described for the AXM by way of example. Suitable programming device connected (SmartStick AX for PIN code ü keypad AX, SmartCD2.G2 for PIN code keypad 3068) PIN code list or matrix screen open. ü...
  • Page 25 9. Reset PinCode keypad AX (Manual) 25 / 34 3. Select the programming device from the ▼ Programming device drop- down menu with which you wish to reset your PIN code keypad. 4. Click on the Reset button NOTE Resetting PIN code keypads that do not form part of the project Your AXM Plus can also reset PIN code keypads that were not created in the same project.
  • Page 26 9. Reset PinCode keypad AX (Manual) 26 / 34 PIN code keypad is reset.

  • Page 27: Feedback Signals

    10. Feedback signals PinCode keypad AX (Manual) 27 / 34 10. Feedback signals Signalling PinCode keypad AX Green + beep PIN correct Green + short beep Keystroke BLE interface woken up, ready for Flickering green + beeping programming Red + beep PIN incorrect PIN code keypad AX programmed, Orange + beep (after pressing a key...

  • Page 28: Technical Data

    11. Technical data PinCode keypad AX (Manual) 28 / 34 11. Technical data Dimensions 96 mm x 96 mm x 16 mm Weight About 100 g with batteries Fastening Adhesive pad or screw attachment Material ABS plastic Anthracite grey (similar to RAL Colour (housing) 9007), semi-transparent rear panel/base plate Colour (button labelling)

  • Page 29: Scale Drawing

    11. Technical data PinCode keypad AX (Manual) 29 / 34 11.1 Scale drawing...

  • Page 30: Drilling Template

    11. Technical data PinCode keypad AX (Manual) 30 / 34 11.2 Drilling template...

  • Page 31: Declaration Of Conformity

    12. Declaration of conformity PinCode keypad AX (Manual) 31 / 34 12. Declaration of conformity The company SimonsVoss Technologies GmbH hereby declares that the articles (SV-PINCODE.AX) comply with the following guidelines: 2014/53/EU -RED-  or for the UK: UK statutory 2017 No. 1206 -Radio equipment- 2011/65/EU -RoHS- ...

  • Page 32: Help And Other Information

    13. Help and other information PinCode keypad AX (Manual) 32 / 34 13. Help and other information Information material/documents You will find detailed information on operation and configuration and other documents on the website: https://www.simons-voss.com/en/documents.html Software and drivers Software and drivers can be found on the website: https://www.simons-voss.com/en/service/software-downloads.html Declarations of conformity You will find declarations of conformity and other certificates on the...
  • Page 33 13. Help and other information PinCode keypad AX (Manual) 33 / 34 Address SimonsVoss Technologies GmbH Feringastr. 4 D-85774 Unterfoehring Germany...
  • Page 34 This is SimonsVoss SimonsVoss, the pioneer in remote-controlled, cable-free locking technology provides system solutions with a wide range of products for SOHOs, SMEs, major companies and public institutions. SimonsVoss locking systems combine intelligent functionality, high quality and award- winning design Made in Germany. As an innovative system provider, SimonsVoss focuses on scalable systems, high security, reliable components, powerful software and simple operation.
