Set up DMX channel from control panel. When fixture is in 3 DMX channel mode, you will only able to set up from Ch1 to
Ch3. When fixture is in 25 DMX channel mode, you will only able to set up from Ch1 to Ch25.
Use "Up" and "Down" button to set up each channel value from <000> to <255>, press "Enter" to save new setting.
Auto Mode
This fixture has 36 built-in programs. Entered "Auto" mode, use "Up" and "Down" button to select the built-in programs
"Auto 1 ~ Auto 36", then press the "Enter" to confirm. Use "Up" and "Down" button to select the operating speed of the
program from 000 to 255, press "Enter" to save new setting. You have to use "Effect on Auto" mode to adjust the
brightness and add strobe effect to auto run.
Effect on Auto
Use "Effect on Auto" to switch on dimmer and strobe function to auto mode. Entered "Effect on Auto" mode, use "Up" and
"Down" button to select dimmer level, then press the "Enter" to confirm. Use "Up" and "Down" button to select strobe
speed from 000 to 255, press "Enter" to save new setting.
Master/Slave Mode
Set the master fixture to auto or manual modes.
Entered "Master" mode, use "Up" and "Down" button to select "No", press "Enter" to set fixture to slave mode.
Use DMX to link master and slave fixture together.
DMX Data
When there is a '*' flashing, the StrobeX is not receiving any DMX signal. A solid '*' indicated DMX signal is being
received. DMX takes priority over all other functions when a signal is being received.
Once DMX signal is lost, the StrobeX will revert back to the original setting, which also could be DMX or Manual or
Automatic mode.

DMX Chart

3 channels Mode
Channel Value
1 000-255
2 000-255
3 000-255
6 channels Mode
Channel Value
1 000-255
2 000-255
3 000-255
4 000-255
5 000-255
6 000-255
www.event-lighting.com.au
Function
Red: 0% ~ 100%
Green: 0% ~ 100%
Blue: 0% ~ 100%
Function
Master dimmer
Strobe speed and repetitions
Strobe interval (0 = longest, 255 = shortest)
Random strobe
Special effect
Speed of special effect
