Dmx Address Setting; Dmx Modes Setting - Event Lighting STROBEXRGB User Manual

Menu Map
Address <001> to <512>
Channel 3, 6, 9, 18, 25
Option Standard, Quiet
Channel 3 Mode
Channel 6 Mode
Monitor
Channel 9 Mode
(Manual
Channel 10 Mode
mode)
Channel 18 Mode
Channel 25 Mode
Auto Auto00
Auto01
Auto02
....
Auto36
Effect Dimmer
on Auto
Strobe
MasMode Yes
No
Back L on
60s
120s
300s
Temp Temp1
Temp1
Info Test 1
Test 2
Reset
Version
Dimmer
Speed
Control
DMX Address
After select the "Address" and press "Enter", use "Up" and "Down" button to select the desired DMX address, press
"Enter" to save new setting.
DMX Modes
After select the "Channel" and press "Enter", use "Up" and "Down" button to select the desired DMX channel mode, press
"Enter" to save new setting.
Manual Mode
It is manual control mode according to DMX chart without DMX controller.
www.event-lighting.com.au
CH:01 to CH:03
CH:01 to CH:06
CH:01 to CH:09
CH:01 to CH:10
CH:01 to CH:18
CH:01 to CH:25
Speed <000> to <255>
<000> to <255>
<000> to <255>
Master or Slave
XXº
XXº
Yes or No
<000> to <007>
4
DMX address
DMX channel modes
Select quite mode or standard mode
Select DMX channel mode first, set up each channel
values to manual control according to DMX chart.
Select auto program and adjust auto run speed
Adjust dimmer level and switch on strobe at different
speed for auto run
Select master/slave mode
Master mode off
Back light always stays on
Back light turns off after 60s
Back light turns off after 120s
Back light turns off after 300s
Display current temperature on LED panel
Display current temperature on chassis
Test mode without strobe
Test mode with strobe
Recover to factory default
Display current version
Fade Time
