RTCC (Real Time Clock Calendar)

The device has a real time clock calendar. The time is synchronized continuously when connected to the server.
1.8

Data Logging and Measurement Interval

The values of every measurement are saved in the memory with the time stamp. At a measurement interval of
one minute, it is possible to save data of one month, which corresponds to 44,000 pairs of measured values.
When the ring memory is full, the oldest values are overwritten.
1.9

Indicator and Button

The device has a button and multicolour LED for use and indication of the operating state. The button is used
to start the device or switch it off in battery mode. The LED indicates the device status and whether it was
possible in the current measurement interval to carry out a valid measurement and send the data to the
monitoring system.
LED Status Indicator for LAN Devices
Pairing
Trigger
1s press
Remove pairing
Trigger
8s press
Device status update
Trigger
1s press
Automatic (every 5 seconds)
LED Status Indicator for Wireless Devices
 
© 2018 ROTRONIC AG Bassersdorf
Action
Confirms pairing
Action
Removes pairing, stops logging
and turns off device
Action
Shows the current status
Shows the current status

Switzerland
Instruction Manual
LED
n x orange, the LED flashes
orange when the
demand is open
LED
3 x red, the pairing information
stored in the logger is deleted
LED
1 x green, the connection to the
server is good
1 x red, battery low
2 x red, there is no connection
to the server
1 x green, the connection to the
server is good
2 x red, there is no connection
to the server
