If necessary:
7
Connect the device to a
power supply.
The wall bracket is
fastened to the wall with
screws according to the
drilling template. The
8
screws may only protrude
so far that the device can
click into place properly
when put on to the
fastened cover.
5
The screws must not be tightened.
6
Only use the screws provided in the package. Screw specifications: M3.5. head strength 2.5 mm, head
diameter 7 mm
 
