RMS-LOG Wireless / LAN Data Loggers
E-M-RMS-LOG-V1.4.docx
3
Installation
There is a difference between mechanical installation of the wall housing and the DIN top hat rail housing. This
manual only describes installation of the wall housing. Installation of the DIN top hat rail housing requires no
special handling. All terminal markings are identical to those of the wall housing.
The following instructions describe installation of the data logger step by step.
Press a blunt object (e.g.
screwdriver in the AC1321
mounting kit) lightly into the
1
hole opening on the top
side of the housing. The
flap springs open.
Press the cover to the back
2
and take off from the basic
unit.
© 2018
ROTRONIC AG
Bassersdorf
Switzerland
Instruction Manual
Page 13 of 35
