Rotronic RMS Wall mount Data Logger Instruction Manual page 14

RMS-LOG Wireless / LAN Data Loggers
E-M-RMS-LOG-V1.4.docx
The cover has two
suspension openings and
3
two additional prepared
fastening possibilities
Insert the batteries at the
back of the device and
remove the insulation
strips.
4
Make sure they are
inserted correctly. The
poles are marked on the
battery and in the battery
compartment.
3
Only the mounting points provided should be used for mounting.
 
© 2018 ROTRONIC AG Bassersdorf
3
.

Switzerland
Instruction Manual
Page 14 of 35
