Only for LAN devices:
Make a round opening in
the large rubber seal (use
5
the mounting cone in
AC1321), pass the cable
through it and fit the rubber
plug in the cover.
Only for LAN devices:
Plug the cable into the
4
device . For secure
6
fastening and to ensure a
reliable data link, make
sure it clicks in audibly.
4
The connected cable may not exceed a length of 30 m at most. Disruptions can occur in operation if a longer
cable is used!
 
