en | 10 | Power DC
plus
25kW Wallbox Charger Installation Manual

8.0 System Codes

Alarm Code
004001
004002
004003
004004
004005
004006
004007
004008
004009
00400A
00400B
00400C
00400D
00400E
00400F
004010
004011
004012
004013
004014
004015
004016
004017
004018
004019
004021
004022
004023
005001
005005
005006
005007
005008
005009
00500C
00500D
00500E
00500F
006001
579604 | REV. A | 12.12.2016
System input voltage is higher than workable range ( > 305 volt)
System input voltage is lower than workable range ( < 170 volt)
System output voltage is higher than EV battery maximum voltage
Request output current from EV is higher than present EVSE ability
The temperature of air inlet or input contactor is higher than workable range ( > 60
degree C )
The temperature of CCS combo charging plug is higher than workable range
REMA => ( > 85 degree C )
Phoenix => ( > 75 degree C )
The air filter need to be replaced
System fan is attenuated so that need to be replaced
The self-test of system controller is failure
Emergency button is pressed
The user authorized by backend is failed
The user authorized by EVSE itself is failed
The temperature sensor of air inlet is broken
The temperature sensor of input contactor is broken
SPD trigger
Output fuse at CCS side is broken
Output fuse at CHAdeMO side is broken
The temperature sensor of CCS combo charging plug is broken
Yhe temperature of air inlet or input contactor is lower than workable range ( < - 40
degree C )
User stops charging
The plug-in times of CCS charging plug is more than 10000 times
The plug-in times of CHAdeMO charging plug is more than 10000 times
System is timeout if user doesn't plug-in in 5 mnutes after authorized
Charging time is up
System data storage is not enough.
Charging is remotely stopped by backend office
Input voltage is drop
System L1 input voltage is lower than workable range ( < 170 volt)
Communication with CHAdeMO EV is broken
Communication with CCS EV is broken
Power rectifier is broken
Communication with CCS controller is broken
Communication with aux. power module is broken
Communication with relay control module is broken
Communication with display module is broken
Communication with RFID module is broken
3G module is not ready (module itself or SIM)
WiFi module is not ready
3G connection is disconnected from APN
Description
