25kW Wallbox Charger Installation Manual
Alarm Code
00A002
00A003
00A006
00A007
00A008
00A009
00A00A
00A00B
00A00C
00B001
00B002
00B003
00B004
00B005
00B006
00C001
00C002
00C003
00D001
00D002
00D003
00D006
00D007
00D008
00D009
00D00A
00D00B
579604 | REV. A | 12.12.2016
Input contactor 1 is driven fault
Input contactor 2 is welding
The positive side of output relay for CCS charging is driven fault
The positive side of output relay for CHAdeMO charging is welding
The positive side of output relay for CHAdeMO charging is driven fault
The negative side of output relay for CCS charging is welding
The negative side of output relay for CCS charging is driven fault
The negative side of output relay for CHAdeMO charging is welding
The negative side of output relay for CHAdeMO charging is driven fault
The firmware update of aux. power module is failure
The firmware update of relay control module is failure
The firmware update of LCM module is failure
The firmware update of CCS charging module is failure
The firmware update of CHAdeMO charging module is failure
The firmware update of power converter module is failure
PLC module for CCS charging is broken
CCS proximity is disconnected
Stop charging by CCS EV
No charging permission come from CHAdeMO EV
Battery malfunction come from CHAdeMO EV
Battery incompatibility with CHAdeMO EV
Present output current is different from target current
Battery OTP come from CHAdeMO EV
Present output voltage is different from target voltage
Position shift alarm is come from CHAdeMO EV
EV other fault is come from CHAdeMO EV
CHAdeMO connector lock is broken
Description
