- Page 1 Your Global Automation Partner TBPN-L1-FDIO1-2IOL Safety Block I/O Module Safety manual - Translation...
- Page 2 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 3: Table Of Contents
Table of Content About this document Scope Safety Integrity Level/Performance Level/Category Product description Intended use 4.1.1 Foreseeable misuse Device overview Type plate Switches and connectors Block diagram Safety function Safe status Fatal Error Safety planning Prerequisites Reaction time Safety characteristic data Operating instructions General Before operation... - Page 4 Appendix: Designations and abbreviations Appendix: Function tests Appendix: Document history Appendix: Technical data Appendix: Declaration of Conformity Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 5: About This Document
Other issues are not considered. All instructions must be followed in order to assure functional safety. Always make sure that this is the latest version of the safety manual at www.turck.com. The German version is considered the definitive document. Every care was taken in the produc- tion of the translations of this document. -
Page 6: Product Description
The use in explosive areas ■ Outdoor use ■ The permanent use in liquids Device overview 38,8 30,2 60,4 230,5 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 7: Type Plate
Type plate TBPN-L1-FDIO1-2IOL Ident-No.: 6814053 Hans Turck GmbH & Co. KG Charge code: Witzlebenstr.7 YoC: D-45472 Mülheim a. d. Ruhr www.turck.com Switches and connectors Meaning Meaning Power IN Power OUT FDI0/1, safety input FDI2/3, safety input FDX4/5, safety in-/output FDX6/7, safety in-/output... -
Page 8: Safety Function
Further information about the reaction time can be found in the online help for the software „Turck Safety Configurator” (see also „7.2.4 Configuring“ on p. 12). Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 9: Safety Characteristic Data
Execute a functional test every twelve months. ➤ ➤ The device must not be repaired. If problems occur with regard to functional safety, TURCK ➤ ➤ must be notified immediately and the device must be returned immediately to: Hans Turck GmbH & Co. KG Witzlebenstraße 7... -
Page 10: Before Operation
Mount the device onto a pre-drilled and grounded mounting surface. The maximum ➤ ➤ tightening torque for the screws is 1.5 Nm. M6 (2x) max. 1.5 Nm 218 [5.58] Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 11: Connection
7.2.2 Connection ATTENTION Loss of protection class IP65/IP67/IP69K Damage to the device due to invasive foreign material or liquids Seal unused sockets, connectors and covers carefully. ➤ ➤ Use appropriate 7/8" sealing caps, e.g. type RKMV-CCC (not included in the scope of ➤... -
Page 12: Address Assignment
In case of a device ex- change, the device configuration can be transferred to another device using the memory stick. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 13: Operation
Operation 7.3.1 Indication elements During operation, the LEDs have the following functions: Color Meaning ETH1 green Link established, 100 Mbps green blinking Ethernet Traffic, 100 Mbps yellow Link established, 10 Mbps yellow blinking Ethernet Traffic, 10 Mbps ETH2 green Link established, 100 Mbps green blinking Ethernet Traffic, 100 Mbps yellow... -
Page 14: Output Error Behavior
= FE 1 = RX + 2 = TX + 3 = RX – 4 = TX – flange = FE Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 15: Power Supply
Power supply 1 BK = GND V2 2 BU = GND V1 3 GNYE = FE 4 BN = 24 VDC V1 5 WH = 24 VDC V2 Safety inputs 1 = V 1/T1 2 = FDI (T2) 3 = GND (V1) 4 = FDI (T1) 5 = T2 Safety in-/outputs... -
Page 16: Appendix: Connection Examples
M-connector of the respective TBPN-L1… 1 n.c. output (pin 2). 2 FDO – 3 n.c. 4 FDO + 5 n.c. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 17: Appendix: Designations And Abbreviations
Appendix: Designations and abbreviations Abbreviation Meaning Diagnostic Coverage E/E/PE-system Electrical/electronic/programmable electronic system Hardware failure tolerance MTTF Mean Time To Failure Dangerous Probability of dangerous failure on demand Average frequency of dangerous failure per hour Performance Level Safety Integrity Level Appendix: Function tests Ensure that the function test is only carried out by qualified personnel. -
Page 18: Appendix: Technical Data
Interval between 2 test pulses, typical 500 ms Interval between 2 test pulses, min. 250 ms Max. output current 2 A (resistive) Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... - Page 19 Max. total current for device 9 A, derating curve: ∑ I [A] [°C] Max. output current 2 A, (DC-load) derating curve: I [A] [°C] The user has to provide an additional overcurrent protection on site. General Information Max. cable length –...
-
Page 20: Appendix: Declaration Of Conformity
Luogo e data del rilascio / Miejsce i data Nome e funzione della persona autorizzata / wydania Nazwisko, stanowisko i podpis osoby upoważnionej Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... - Page 21 28 subsidiaries and over 60 representations worldwide! D301391 | 2018/01 *D301391ßß1801* www.turck.com...
