- Page 1 Your Global Automation Partner TBIL-M1-16DXP-B I/O Hub with IO-Link Instructions for Use...
- Page 2 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 3: Table Of Contents
Table of Contents About These Instructions ....................... 5 Target groups........................ 5 Explanation of Symbols Used .................. 5 Additional Documents .................... 5 Feedback About These Instructions ................. 5 Notes on the Product ........................ 6 Product Identification .................... 6 Scope of Delivery...................... 6 Legal Requirements ..................... - Page 4 11 Maintenance........................... 28 12 Repair............................... 28 12.1 Returning Devices ...................... 28 13 Disposal ............................ 28 14 Technical Data.......................... 29 15 Appendix: Declaration of Conformity .................. 31 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 5: About These Instructions
This symbol denotes actions that the user must carry out. RESULTS OF ACTION This symbol denotes relevant results of actions. Additional Documents The following additional documents are available online at www.turck.com: Data sheet Declaration of Conformity IO-Link devices commissioning manual... -
Page 6: Notes On The Product
For further inquiries in Germany contact the Sales and Service Team on: Sales: +49 208 4952-380 Technology: +49 208 4952-390 Outside Germany, please contact your local Turck representative. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 7: For Your Safety
Intended Use These devices are designed solely for use in industrial areas. The block module TBIL-M1-16DXP-B is an IO-Link device (Class B) and serves as I/O hub between field devices (sensors/actuators) and the IO-Link master. The hub has 16 I/O channels. -
Page 8: Product Description
The device provides diagnostics for power supply and short circuit of the sensors and actuators on the IO-Link master. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 9: Mounting
Mounting The device is mounted via four M4 screws on a flat and pre-drilled mounting surface. „ Fasten the module to the mounting surface with 4 M4 screws. The maximum tightening torque for the screws is 0.5 Nm M4 (4x) max. -
Page 10: Connecting
2 = 24 VDC (V2) 3 = GND (V1) 4 = C/Q (IO-Link) 5 = GND (V2) Fig. 4: Pin assignment IO-Link Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 11: Supply Concept
6.1.1 Supply Concept The I/O hub TBIL-M1-16DXP-B is supplied via the IO-Link connector with two galvanically isol- ated voltages V1 and V2 through the IO-Link connector. The IO-Link channels are separated into the different potential groups "detachable I/O" (supplied through V2) and "non-detach- able"... -
Page 12: Connecting Digital Sensors And Actuators
Supply sensors and actuators from SELV or PELV power supplies. „ Decouple external circuits that are not designed as SELV/PELV systems by optocouplers, relays or other measures. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 13: Using The Device In Safety Applications
Using the Device in Safety Applications The device is designed in accordance with EN ISO 13849-1 “Safety of machinery - Safety-related parts of control systems”. Safety Function The safety function is executed by the higher-level system. The supply voltage (V2) of the outputs at C4…C7 can be safely switched off by an external safety relay or a safety PLC. -
Page 14: Safety Planning
If the maximum duty cycle is reached: Execute switch-off of the V2 voltage group by the safety relay to check the function of the safety system. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 15: Parameterizing And Configuring
[Byte] Hex. (Dec.) 0x00 Direct Parameter Page 1 read only 0x07 Vendor ID read 0x013D only (ID for Turck) 0x08 0x09 Device ID read TBIL-M1-16DXP-B: only 0x1EB303 0x0A 0x0B IO-Link object directory – ISDU device parameters: Identification ISDU Object name... - Page 16 Undervoltage supply V1/V2 (80) only Overcurrent Vsens Connector C0…C7 0x51 Output Short read Overcurrent output 0…15 (81) Circuit only Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
- Page 17 Invert Digital Input – 0x41 (65), Sub Index 0 This parameter inverts the state of the digital input in the process image. Format Length Byte 1 byte 1 bit per channel Default values are shown in bold. Value Meaning Input signal inverted Byte 0 Byte 1 Bit offset...
- Page 18 C7P2 C7P4 C6P2 C6P4 C5P2 C5P4 C4P2 C4P4 C3P2 C3P4 C2P2 C2P4 C1P2 C1P4 C0P2 C0P4 NOTE This parameter can also be set for all connectors of the module via the IODD. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
- Page 19 Output After Error – 0x45 (69), Sub Index 0 This parameter defines the behavior of the output in case of an interruption of the IO-Link com- munication. Format Length Array of Bytes 2 byte 2 bit per channel Default values are shown in bold. Value Meaning Set output to 0...
- Page 20 20.4 V Extended lower threshold: 17.5 V Byte 0 Bit offset Activate diagnostics Threshold Byte 1 Bit offset Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 21: Operating
Operating CAUTION Operating the device outside the specification Slight injuries and equipment damage possible. „ Operate the unit only within the operating temperature specified in the tech- nical data. „ Use only thermally suitable connection cables. Process Input Data Byte Bit offset Inputs C3P2... -
Page 22: Process Output Data
C2P4 C1P2 C1P4 C0P2 C0P4 C7P2 C7P4 C6P2 C6P4 C5P2 C5P4 C4P2 C4P4 Designation Meaning CxPy Output inactive Output active Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 23: Led Displays
LED Displays The device has the following LED indicators: IO-Link communication I/O status 9.3.1 IO-Link IO-Link LED Meaning Green flashing IO-Link communication error-free, valid process data are sent IO-Link communication error or module error Red flashing IO-Link communication error-free, invalid process data or diagnostic (1 Hz) message no voltage supply... -
Page 24: Evaluating Diagnostic Data
Overcur- Overcur- Overcur- Overcur- rent Vsens rent Vsens rent Vsens rent Vsens rent Vsens rent Vsens rent Vsens rent Vsens Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... - Page 25 Overcurrent Output – 0x51 (81), Sub Index 0 Indicates an overcurrent at the corresponding digital output. Format Length Array of Bytes 2 byte 1 bit per output 0 = no diagnostics 1 = diagnostic message Byte 0 Bit offset Overcur- Overcur- Overcur- Overcur-...
-
Page 26: Io-Link Events
Parameter length underrun meter. 0x8035 Function not available Function not available in the device 0x8041 Inconsistent parameter set Inconsistent parameters Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 27: Troubleshooting
Troubleshooting If the device does not function as expected, first check whether ambient interference is present. If there is no ambient interference present, check the connections of the device for faults. If there are no faults, there is a device malfunction. In this case, decommission the device and replace it with a new device of the same type. -
Page 28: Maintenance
Disposal The devices must be disposed of correctly and must not be included in normal household garbage. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 29: Technical Data
Technical Data Technical Data Power supply Operating/load voltage 24 VDC Permissible range 18…30 VDC Operating current From V1: < 100 mA From V2: < 85 mA Total current Max. 4 A per voltage group, V1 + V2: max. 5.4 A Sensor/actuator supply VAUX1 Supply connector C0…C3 from V1 short-circuit proof, 120 mA per connector, with diagnostics... - Page 30 Protection class IP67/IP69K MTTF 79 years Housing material PA6-GF30 Housing color Black Halogen-free Mounting 4 mounting holes, Ø 4,3 mm Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 31: Appendix: Declaration Of Conformity
Appendix: Declaration of Conformity EU-Konformitätserklärung Nr.: 5035-2M EU Declaration of Conformity No.: HANS TURCK GMBH & CO KG / We WITZLEBENSTR. 7, 45472 MÜLHEIM A.D. RUHR erklären in alleiniger Verantwortung, dass die Produkte declare under our sole responsibility that the products... - Page 32 Over 30 subsidiaries and over 60 representations worldwide! 100003088 | 2018/11 100003088 www.turck.com...
