Symmetricom Time Server User Manual page 59

Serial Access
Setting Up a HyperTerminal Session
To set up a HyperTerminal session:
1. From the File menu in the session window, select Properties.
TimeVault's Properties dialog box appears, showing the Connect To tab:
2. Select the Settings tab and click the Terminal keys radio button:
3. In the Emulation box, use the drop-down menu to select VT100 terminal type (do
not select the Auto detect option).
6000-100Ch3.fm Rev. D TimeVault™ User's Manual
Chapter 3: Remote Operation
3-45
