Symmetricom Time Server User Manual page 58

Chapter 3: Remote Operation
4. In the Connect using box, use the drop-down menu to select your modem's Com
port (COM1 in this example), then click OK.
The COM1 Properties dialog box appears, showing the Port Settings tab:
5. Edit the fields in the Port Settings dialog box as follows:
Bits per second:
Data Bits:
Parity:
Stop Bits:
Flow control:
6. Click OK.
TimeVault's HyperTerminal window appears, indicating that TimeVault is now
connected through the Utility Port:
3-44
9600
8
None
1
None
TimeVault™ User's Manual
Serial Access
6000-100Ch3.fm Rev. D
