3.3

Remote control

The CombiMaster Inverter/Charger can be monitored from a remote panel like the SmartRemote or a
Touch 5 (in a CZone network). Some settings can only be adjusted from a laptop/notebook or PC
connected to the CombiMaster Inverter/Charger via a USB Interface.
3.4

Protection

•
Overload or short circuit; while in the inverter mode, the CombiMaster Inverter/Charger will shut
down after 5 seconds of 200% overload or after 10 seconds 150%.
•
Transfer switch overload; the transfer switch of the CombiMaster Inverter/Charger is protected
against overload and short circuit. When the current through the transfer switch of the CombiMaster
Inverter/Charger is too high, the thermal fuse (item 8 on page 7) will disconnect the AC input.
•
High temperature; if the ambient temperature of the CombiMaster Inverter/Charger exceeds 104°F
[40°C], it will reduce power. If it exceeds 140°F [60°C], it will shut down, trigger the status LEDs and
optionally a remote alarm. As soon as the temperature drops below the factory default threshold,
the inverter is powered up automatically or the charger resumes its charge current.
•
Battery low/high; the CombiMaster Inverter/Charger can warn for low or high battery voltages by
triggering status LEDs and CZone/MasterBus alarms.
CAUTION!
The CombiMaster Inverter/Charger is not protected against:
- serious over voltage on the AC input;
- serious continuous overload on the AC output.
Make sure AC input is within the range of 90-135V
AC OUT never exceeds 40A.
See section 6.2 on page 26 for an overview of the status LEDs. See chapter 5 on page 19 for the
required settings.
CombiMaster 120V Series – User and Installation Manual
and the continuous load connected to
AC
9
