CombiMaster 120V Series – User and Installation Manual
8.3

Transfer system specifications

Model
AC input (switched)
AC input fuse
AC output
Transfer speed
Transfer voltage range
Transfer frequency range
Power sharing
AC IN support
Auto-synchronize with AC input
*
Exceeding the max. allowable output current may damage the CombiMaster Inverter/Charger.
8.4

Miscellaneous

Model
Dimensions, h×w×d
Weight
Protection degree
Safety class
Operating temperature
Storage temperature
Pollution degree
Relative humidity
Standards, approvals & listings
Front panel display
Battery temperature sensor
Cooling
Parallel stacking
3-phase configuration
MasterBus powering
LEN (Load Equivalence Number) 0
Protections
AC input:
AC IN limit
Frequency monitoring
Voltage monitoring
Output:
Short circuit protection
Overload protection
Over temperature protection
AC backfeed protection
All models
30A
Yes, resettable thermal fuse
Max connected continuous load: 40A*
10ms for narrow input range, 20ms for wide range
90-140V
40-65Hz
Yes
Yes
Yes
All models
17.6 × 11.2 × 6.1 inch [448 × 284 × 155 mm]
20.5 lb [9.3 kg]
IP 23 vertical wall mounted, IP 21 horizontal tabletop mounted
IEC protection class I
14°F to 140°F, derating above 104°F
[-10°C to 60°C, derating above 40°C]
-22°F to 158°F [-30 to 70°C]
3
Max 95% relative humidity, not condensing.
UL1741, UL1236, FCC Class B
Yes, shows AC input sate, Inverter state, charger state
Yes
Vario fans
No
No
Yes
Adjustable
Relay disconnects when frequency is out of range
Relay disconnects when voltage is out of range
Yes (inverter only)
Yes (integrated resettable thermal fuse)
Yes
Yes
