Mastervolt Mass Combi 230V Quick Installation

Quick installation
This Quick installation guide provides a brief overview of a basic stand-alone installation of the
1
Mass Combi. However; please review the entire user's manual for parallel connection, additional
features and connections and to ensure best performance and years of trouble-free service.
All electrical systems (DC and AC) must be disconnected from any power source during the
2
entire installation! Use isolated tools!
Read safety instructions (chapter 2 of the user's manual).
3
Check the contents of the delivery
A. Mass Combi
B. Inverter Charger Control (ICC) with mounting box and Communication cable (6m)
(only included with the models 12/2000, 12/4000, 24/2000 and 24/4000)
C. Battery temperature sensor
D. User- and installation manuals
E. MasterBus – Serial interface + serial communication cable (60cm / 24 inch) + MasterBus terminator
(only included with models 12/2500 and 24/2500)
Contact your supplier if one of the items is missing. Do not use the Mass Combi if it is damaged.
4
Check from the identification label whether the
battery voltage is the same as the DC-input
voltage of the Mass Combi (e.g. 12V battery set
for a 12V battery voltage). Also be sure that the
AC output voltage and output power of the
Mass Combi satisfies loading requirements.
