32
CombiMaster 120V Series – User and Installation Manual

8 TECHNICAL DATA

Specifications are subject to change without prior notice.
8.1

Inverter specifications

Model
Part number/product code
Nominal battery voltage
Inverter output voltage
Frequency
Continuous power
@Tamb=77˚F [25˚C]
Continuous power
@Tamb=104˚F [40˚C]
Max. peak load (10sec)
Max. peak load (5sec)
Output waveform
Max. efficiency
DC input voltage range
Switch off voltage low battery
Switch on voltage low battery
Switch off voltage high battery
Switch on voltage high battery
Max. ripple on DC @ full load
Nominal DC current at full load
Recommended battery capacity
(based on gel batteries)
No load DC power
consumption
Inverter off mode
Energy saving mode
Normal operation mode
12V/2000W- 12V/3000W-
100A 160A
35512000 35513000
12V 12V
120V (inverter only) or 90-140V (AC input support mode)
50Hz / 60Hz (configurable)
2000W 3000W
2000W 2600W
6-18V 6-18V
10.2V 10.2V
11.5V 11.5V
16.0V 16.0V
15.0V 15.0V
200A 300A
200-1000Ah 320-1600Ah
24V/2000W-
60A
35522000
24V
2000W
2000W
150%
200%
True sine
91%
12-32V
20.4V
23.0V
32.0V
30.0V
15%
100A
120-600Ah
<2mA
<10W
<30W
24V/3000W-
70A
35523000
24V
3000W
2600W
12-32V
20.4V
23.0V
32.0V
30.0V
150A
140-700Ah
