2. Code length - number of digits (Code)
Number of digits to use in the keyboard code. 4 or 6.
NOTES:
- See functioning (chapter "Add users - Add"):
Standby Mode
3. Code is shown. Confirm with the OK key.
C o d e
1 beep
4. 0006 is shown. Using the scroll keys the following sequence will appear: 0006, 0004, 0006.... Select the
number of required digits: 4 or 6 and confirm with the OK key.
0 0 0 6
1 beep
Communications protocol in centralised system (Prot)
No autonomous function
Resetting the Master Code (where the previous code is forgotten)
This operation is carried out by electrically modifying the equipment, in the aim of ensuring
it is impossible for anyone without physical access to the equipment to modify it in any way.
1. Disconnect the system's power supply.
Mode Not Set-Up
2. Short-circuit "Bs" and the system "-".
If the system is equipped with an exit button, just press and hold it down.
3. Reconnect the system's power supply and do not remove the short circuit.
Once powered up Ini will appear
on the display
Enter the master fingerprint or
present the master card
Pag 28
1. Enter the master fingerprint
A d d
Enter Programming Mode
1 2 3
4 5 6
7 8 9 +
x -
0
REMOTE UNIT
FOR ACCES CONTROL
1 2 3
4 5 6
7 8 9 +
x -
0
REMOTE UNIT
FOR ACCES CONTROL
I n i
0 y
d 2. 2
2. Search using the menu's scroll keys:
Code
1 beep
0 0 0 4
1 beep
1 beep
1 beep
1 2 3
4 5 6
7 8 9 +
x -
0
REMOTE UNIT
FOR ACCES CONTROL
