Thank you for purchasing the Kirsch
operation, and care, your new shades will provide years of beauty and performance.
To get started, unpack the shade and remove all foam/packaging materials. Check that all
parts shown on the packing list are included with the order. Please thoroughly review this
instruction booklet before beginning the installation.
IMPORTANT: Cords are wrapped around a cord organizer located approximately 6" from
the top of the moving rail. Please do not unwrap the cords until instructed to do so.
Tools and Fasteners Needed
⁄
" Hex, Flat Blade and magnetic-tipped Phillips Screwdrivers
1
■ ■
4
Level (laser level is recommended)
■ ■
Measuring tape and pencil
■ ■
Power drill,
⁄
" drill bit, and
3
■ ■
32
Scissors
■ ■
In addition, you will need fasteners designed to work with your specific mounting surface(s).
#6 Hex Head Screws (Provided). Two 1
■ ■
Longer #6 Hex Head Screws (Not Provided). If using spacer blocks, use #6 screws long enough for a secure attachment.
■ ■
Speed Nuts and Screws (Provided). Extension brackets come with speed nuts and screws.
■ ■
Drywall Anchor (Not Provided). Use drywall anchors when mounting into drywall.
■ ■
Recommended Number of Installers
Two installers are recommended for shades over 84" wide.
■ ■
Installation Overview
Installation of Vertical Celullar shades varies based on the shade mounting type, stacking design, and the valance type selected.
Mounting Types and Window Terminology
Review the mounting types and basic window terminology illustrated below. Determine if your shade is an outside mount or
■ ■
inside mount. For ceiling mount applications, refer to the inside mount instructions.
GETTING STARTED
®
Cellular Shade Collection. With proper installation,
⁄
" hex driver
1
4
⁄
" screws are provided per installation bracket.
1
2
#6 x 1
"
Longer #6 Hex Head Screw
1
2
Hex Head Screw
for Use with Spacer Blocks
(Provided)
(Not Provided)
INSTALLATION
Molding
Head Jamb
Jamb
Jamb
Window or
Patio/Sliding Door
Floor
Shade mounts outside
door or window opening.
Speed Nut
and Screw
(Two Provided with
Each Extension Bracket)
Outside Mount
Shade fits within door
or window opening.
2
Do Not
Unwrap
Cords
Inside Mount
