GV-IP Decoder Box Plus / Lite
No. Name
1 Network
2 Audio Out
3 VGA
4 HDMI
5 USB
6 DC 12V
16
1 3
2
Figure 1-9
Function
Connect to the network.
Connect to a speaker.
Connect to a VGA monitor.
Connect to an HDMI-compliant display device.
Connect to a GV-Joystick V2, USB mouse, or USB storage device.
Connect to power by using the supplied power adapter.
6
5
4
