Quick Start Guide

GV-CR1320 Camera Reader
Thank you for purchasing GV-CR1320 Camera Reader. This guide is designed to assist the new user in
getting immediate results from the controllers. For advanced information on how to use GV-CR1320, please
refer to GV-CR1320 Camera Reader User's Manual
CR1320-QG-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-CR1320 and is the answer not in the manual?

Questions and answers

Related Manuals for GeoVision GV-CR1320

Summary of Contents for GeoVision GV-CR1320

  • Page 1: Quick Start Guide

    Quick Start Guide GV-CR1320 Camera Reader Thank you for purchasing GV-CR1320 Camera Reader. This guide is designed to assist the new user in getting immediate results from the controllers. For advanced information on how to use GV-CR1320, please refer to GV-CR1320 Camera Reader User's Manual...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Table Of Contents

    3.2 Connecting via GV-WTR......................8   3.3 Connecting Input Devices ....................... 9   3.4 Connecting Output Devices ....................9   3.5 Powering on GV-CR1320...................... 10   4. Accessing GV-CR1320 ..............11   4.1 Web Browser..........................11   4.2 Checking the Dynamic IP Address..................12  ...

  • Page 4: Installation Considerations

    When placed at a building gate, GV-CR1320 should be about 1.4-1.5 meters above the ground.  When placed at a parking lot gate, GV-CR1320 should be about 1.2 meters above the ground to match the height of vehicles. Face Detection Limitations ...

  • Page 5: Introduction

    GV-CR1320 Camera Reader User’s Manual from our website. 1.1 System Requirements To access the functions and settings of GV-CR1320 on the Web interface, ensure your PC has good network connection and use one of the following web browsers: ...

  • Page 6: Packing List

    V17.1 or later V17.1 or later GV-Vital Sign Monitor GV-Video Gateway / Recording Server V1.4.2 or later 1.2 Packing List   GV-CR1320 Mounting Plate   Standard Screw x 2 Plastic Screw Anchor x 2   Security Tube Torx Wrench ...

  • Page 7: Optional Accessories

    Introduction 1.3 Optional Accessories Optional devices can expand the capabilities and versatilities of your GV-CR1320. Consult our sales representatives for more information. GV-AS series are controllers used to manage up to 4/8 doors via GV-AS2120 / 4110 / connected readers and have the capability of storing and granting 4111 / 8110 / 8111 / restricting access for up to 100,000 cards.

  • Page 8: Overview

    Status below. Resets all configurations to default factory settings. See 7 Default Button Restoring to Factory Default. Power Cable Connects to power supply. See 3.4 Powering on GV-CR1320. Connects to network and power supply. See Chapter 3 Ethernet Port Connecting GV-CR1320.
  • Page 9 Introduction LED and Beeper Status Condition Beeper Blue (Connected to GV-ASManager) Ready Purple (Disconnected from GV-ASManager) Access Denied Displays red LED momentarily Two short beeps Access Granted Displays green LED momentarily One long beep One short beep Touchpad activated Flashes blue momentarily Three short beeps after 30 Touchpad ignored Returns to blue/purple LED...

  • Page 10: Installation

    2. Installation After the location of your GV-CR1320 is decided, follow the steps below to install the camera access controller. 1. Attach the single gang power box to the wall. 2. Place the mounting plate on the single gang power box and secure with the 2 standard screws provided.
  • Page 11 Installation 4. Secure the security screw on the bottom with the mounting plate.

  • Page 12: Connecting Gv-Cr1320

    3. Connecting GV-CR1320 There are two ways to connect GV-CR1320 to a GV-AS Controller, as illustrated below: 3.1 Connecting by Network Door Network (sends card number) GV-ASManager GV-AS Controller GV-CR1320 Network (sends live view) 3.2 Connecting via GV-WTR Door Wiegand 1...

  • Page 13: Connecting Input Devices

    All inputs are dry contact and can be configured as normally open (NO) or normally closed (NC) through the GV-CR1320 Web interface. The default value is NO. To change the input status, see Input Setting, Chapter 4, GV-CR1320 Camera Reader User’s Manual.

  • Page 14: Powering On Gv-Cr1320

    The example below illustrates the connection of a locking device to GV-CR1320. Connect the (+) point on the locking device to the Output COM wire on GV-CR1320, connect the two (-) points of the locking device and the external power supply together, and connect the (+) point on the external power supply to the Output NO or Output NC wire on GV-CR1320 based on the state of the locking device.

  • Page 15: Accessing Gv-Cr1320

    4. Accessing GV-CR1320 4.1 Web Browser To access the functions and settings of GV-CR1320 on the Web interface, ensure your PC use one of the following web browsers.  Browser Internet Explorer 9.x or later  Firefox  Google Chrome ...

  • Page 16: Checking The Dynamic Ip Address

    4.2 Checking the Dynamic IP Address By default, when GV-CR1320 is connected to LAN with a DHCP server, it is automatically assigned with a dynamic IP address. Follow the steps below to look up its IP address. Note: The PC installed with GV-IP Device Utility must be under the same LAN with GV-CR1320.

  • Page 17: Assigning An Ip Address

    Accessing GV-CR1320 4.3 Assigning an IP Address When GV-CR1320 is connected to LAN without a DHCP server, it is assigned with the default IP address of 192.168.0.10. Follow the steps below to assign a new IP address to avoid IP conflict with other GeoVision devices.
  • Page 18 LAN, use the GV-IP Device Utility to look up its current dynamic address. See 4.2 Checking the Dynamic IP Address. If your GV-CR1320 uses a public dynamic IP address, via PPPoE, use the Dynamic DNS service to obtain a domain name linked to the camera reader’s changing IP address first.

  • Page 19: The Web Interface

    Show System Brings up these functions: Video and Audio Configuration, Remote Config, Show Camera Name and Image Enhance. Menu Enables the I/O Control and Visual Automation Panel. 9 I/O Control For details, see Chapter 3, GV-CR1320 Camera Reader User’s Manual.

  • Page 20: Upgrading System Firmware

    6. Upgrading System Firmware GeoVision periodically releases the updated firmware on the website. To load the new firmware into the GV-CR1320, follow the instructions below. 1. In the Live View window, click the Show System Menu button and select Remote Config.

  • Page 21: Restoring To Factory Default

    7. Restoring to Factory Default If for any reason the device is not responding properly, you can reset it to its factory default settings either directly on the device or through its Web interface. 7.1 Using the Web Interface 1. In the left menu, select Management and select Tools. 2.
