GeoVision GV-IP Decoder Box Series User Manual page 21

GV-IP Decoder Box Plus
GV-IP Decoder Box Lite
No. Name
SD Card
1
Slot
2 Default
3 USB
4 LED Indicators
5 Audio In
14
1
2
Figure 1-6
Figure 1-7
Function
Connect to a SD card for local storage of snapshots and firmware
upgrade. Only supported by GV-IP Decoder Box Plus.
Reset the device to the default factory settings. Use a pin to press the
default button for about 10 seconds. The system will then reset and
reboot itself shortly. See 5.2 Restoring Default Settings.
Connect to a GV-Joystick V2, USB mouse, or USB storage device.
Only supported by GV-IP Decoder Box Plus.
The red LED indicates the power is supplied.
The green LED indicates the system is ready for use.
Not functional.
3 4
5
