Table A-2 lists SunFastEthernet Adapter Media Independent Interface signals
and their corresponding pin numbers.

Table A-2 SunFastEthernet Adapter Media Independent Interface Signals (Ultra DB40)

Pin Number Description
1 +5V
2 MDIO
3 MDC
4 RXD<3>
5 RXD<2>
6 RXD<1>
7 RXD<0>
8 RX_DV
9 RX_CLK
10 RX_ER
11 TX_ER
12 TX_CLK
13 TX_EN
14 TXD<0>
15 TXD<1>
16 TXD<2>
17 TXD<3>
18 COL
19 CRS
20 +5V
Interface Signals
Pin Number Description
21 +5V
22 GND
23 GND
24 GND
25 GND
26 GND
27 GND
28 GND
29 GND
30 GND
31 GND
32 GND
33 GND
34 GND
35 GND
36 GND
37 GND
38 GND
39 GND
40 +5V
