Table A-1 SBus Interface Signals (Continued)
Pin No. Description Pin No.
46 PA (26) 63
47 DP 64
48 -12V 65
49 CLK 66
50 BG* 67
51 AS* 68
52 GND 69
53 D (1) 70
54 D (3) 71
55 D (5) 72
56 +5V 73
57 D (7) 74
58 D (9) 75
59 D (11) 76
60 GND 77
61 D (13) 78
62 D (15) 79
SunFastEthernet Adapter User Guide—November 1994
Description Pin No. Description
D (17) 80 +5V
+5V 81 PA (7)
D (18) 82 PA (9)
D (20) 83 PA (11)
D (22) 84 GND
GND 85 PA (13)
D (24) 86 PA (15)
D (26) 87 PA (17)
DA (28) 88 +5V
+5V 89 PA (19)
D (30) 90 PA (21)
SIZ (1) 91 PA (23)
RD 92 GND
GND 93 PA (25)
PA (1) 94 PA (27)
PA (3) 95 RST*
PA (5) 96 +12V
