™ SunFDDI/P 1.0 Adapter User’s Guide Sun Microsystems Computer Company A Sun Microsystems, Inc. Business 2550 Garcia Avenue Mountain View, CA 94043 USA 415 960-1300 fax 415 969-9131 Part No.: 805-0809-10 Revision A, May 1997...
Page 2
Sun. Sun, Sun Microsystems, le logo Sun, Solaris, SunOS, SunFDDI/P, et SunNet Manager sont des marques déposées ou enregistrées de Sun Microsystems, Inc.
FCC radio frequency emission limits. Networking connections can be made using unshielded twisted-pair (UTP) cables. Modifications: Any modifications made to this device that are not approved by Sun Microsystems, Inc. may void the authority granted to the user by the FCC to operate this equipment.
DOC Class A Notice - Avis DOC, Classe A This Class A digital apparatus meets all of requirements the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. DOC Class B Notice - Avis DOC, Classe B This Class B digital apparatus meets all of requirements the Canadian Interference-Causing Equipment Regulations.
Declaration of Conformity Class B IEC801-2 (1991) 4 kV (Direct), 8 kV (Air) IEC801-3 (1984) 3 V/m IEC801-4 (1988) 1.0 kV Power Lines, 0.5 kV Signal Lines Pass (Class D) ______/ S /_________________ DATE Stephen McGoldrick Quality Assurance Manager Sun Microsystems Limited Springfield, Linlithgow...
Page 6
Declaration of Conformity Class B IEC801-2 (1991) 4 kV (Direct), 8 kV (Air) IEC801-3 (1984) 3 V/m IEC801-4 (1988) 1.0 kV Power Lines, 0.5 kV Signal Lines Pass (Class D) ______/ S /_________________ DATE Stephen McGoldrick Quality Assurance Manager Sun Microsystems Limited Springfield, Linlithgow...
How this Book is Organized Preface The SunFDDI/P™ 1.0 Adapter User’s Guide describes how to turn your system into an FDDI station attached to an FDDI network. It is intended for experienced network administrators who are familiar with the Solaris 2.5.1 Hardware: 4/97 operating environment.
If you are connecting the SunFDDI/P card to a network that has a MIC connector, an SC-MIC converter cable is required. Chapter 1, “SunFDDI/P Overview,” describes the SunFDDI/P 1.0 implementation of the FDDI protocols and includes a list of the specifications to which it conforms.
UNIX Commands Chapter 9, “Managing FDDI Stations Using SunNet Manager,” describes how to install the SunNet Manager agents for SunFDDI/P and how to set up the SunNet Manager console to manage them. Chapter 10, “Developing Applications that Run over SunFDDI/P,” describes how to create applications that run over SunFDDI/P, using the DLPI interface for a Solaris 2.x environment.
C shell superuser machine_name# Bourne shell and Korn shell Bourne shell and Korn shell superuser SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Example Edit your .login file. Use ls -a to list all files. machine_name% You have mail. machine_name% su Password: To delete a file, type rm filename.
Prentice Hall, Inc.: 1994 Sun Microsystems SunDocs is a distribution program for Sun Microsystems technical documentation. Easy, convenient ordering and quick delivery is available from SunExpress™. You can find a full listing of available documentation on the World Wide Web: http://www.sun.com/sunexpress/...
If a card is not available, you can email or fax your comments to us. Please include the part number of your document in the subject line of your email or fax message. • Email: smcc-docs@sun.com • Fax: SMCC Document Feedback 1-415-786-6443 SunFDDI/P 1.0 Adapter User’s Guide—May 1997 On-line support...
Page 25
Part 1 — Installing and Configuring SunFDDI/P...
See Chapter 6, “FDDI Network Architecture” for more information on FDDI architecture. The SunFDDI/P 1.0 product is a combination of hardware and software that turns your system into an FDDI station. There are two hardware options: •...
• • • • • SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Provides connection to multimode fiber (SunFDDI/P and SunFDDI/P Dual) networks Supports data transfer rates of up to 100 Mbps Provides power-up self test and system diagnostic tests Provides high reliability and availability through distributed, automatic...
Hardware Installation Device Instances and Device Names Installing SunFDDI/P Adapter Cards Connecting Fiber Optic Cables Link Status Indicator (Diagnostic LED) This chapter tells you where to find step-by-step procedures for installing PCI cards. It describes the convention used to assign device names to SunFDDI/P adapter cards, and tells you how to connect fiber optic cables.
SunFDDI/P supports up to four SunFDDI/P PCI cards installed in one PCI, and up to eight SunFDDI/P PCI cards installed in one machine. SunFDDI/P 1.0 PCI cards are assigned device names of the form pf<inst>, where the instance number <inst> is determined by the number and relative positions of the cards installed.
Installing SunFDDI/P Adapter Cards Caution – The SunFDDI/P PCI card is sensitive to static electricity. Always use the wrist strap supplied with SunFDDI/P when handling the card and ensure that the wrist strap is properly grounded. Handle the SunFDDI/P PCI card by the edges, and avoid touching any of the components.
Figure 2-1 3. Plug the cable into the card connector. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Fiber optic cable has a limited turn radius. Do not bend it in a way that could damage the fiber or cause signal loss.
MIC-to-MIC Coupler A separate MIC (Media Interface Connector) coupler is shipped with the SunFDDI/P 1.0 Adapter product to support MIC-to-MIC network connections. Two different versions of the coupler are available: • • Note – Make sure you properly connect the coupler. An improper connection will “twist”...
2. Blow clean, dry compressed air around the end of the connector and 3. Clean the adapter by running a pipe cleaner moistened in alcohol running 4. Dry the adapter with clean, dry compressed air. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 swab. Cleaning the End of a Fiber Optic Cable around the ferrule to dislodge loose dust and grit.
Link Status Indicator (Diagnostic LED) A link status indicator is mounted on the SunFDDI/P PCI card. The color of the LED indicates the current status of the connection to the FDDI network as follows: • • • • • Refer to Chapter 5, “Troubleshooting and Diagnostics,” for more information on diagnosing problems with your FDDI network.
Installing SunFDDI/P Software Installation Requirements Declaring IP Addresses for SunFDDI/P Installing and Configuring SunFDDI/P Installing SunNet Manager Agents for SunFDDI/P Removing SunFDDI/P This chapter assumes that you have already installed the SunFDDI/P adapter card in your machine and that you are loading the software from a local CD-ROM drive.
The installation script updates the /etc/hosts file on the local machine and enters the IP addresses and host names assigned to the SunFDDI/P interfaces in which it is installed. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Hardware and Software Platforms SunFDDI/P is designed for Sun-4u PCI-based system architectures (32 Mbytes RAM minimum) running a Solaris 2.5.1 Hardware: 4/97...
Installing and Configuring SunFDDI/P Use pkgadd(1M) to install unbundled software. See the Solaris 2.5 Software and AnswerBook Packages Administration Guide for detailed information on installing software products using pkgadd. For detailed instructions on how to load software from a CD-ROM drive mounted on a remote directory, see the Solaris 2.5 Software and AnswerBook Packages Administration Guide.
Page 40
1. Indicate whether you are installing the driver for a diskless client. • • SunFDDI/P 1.0 Adapter User’s Guide—May 1997 press Return. Respond to any prompts that are displayed. Two packages are associated with SunFDDI/P. They contain the device drivers and utilities used to manage your SunFDDI/P station.
Page 41
Is this install for a diskless client [n] [y,n,?] (See Chapter 11, “Setting Up Servers and Diskless Clients” for more information on booting diskless clients across an FDDI network.) The number of SunFDDI/P interfaces found is displayed and you are asked how many interfaces you want to configure.
Page 42
An installation script is executed automatically when you install the SunFDDI/P utilities and man pages (SUNWpft): SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Type n, or press Return, if you are not using SunNet Manager to manage your network; if you are running SunNet Manager agents on another machine;...
2. Eject the CD-ROM from the CD-ROM drive. • If Volume Manager (vold) is running on your machine, the CD-ROM is unmounted automatically when it is ejected: # eject cdrom Installing SunFDDI/P Software SunFDDI/P (Driver) (sparc) 1.0 SunFDDI/P (Man Pages/Utilities) (sparc) 1.0...
2. Use ifconfig(1M) to check the current state of the SunFDDI/P 3. Use ping(1M) to verify that you can send and receive data across the SunFDDI/P 1.0 Adapter User’s Guide—May 1997 If Volume Manager (vold) is not running on your machine, unmount the...
Chapter 5, “Troubleshooting and Diagnostics,” for help. Unloading Drivers The driver for the SunFDDI/P 1.0 adapter can be unloaded while the system is running by using the modunload(1M) command. If the SunNet Manager daemons are running on your system, you must kill that process before you unload the SunFDDI/P driver.
Host name of Console -------> Host name of Console -------> Press Return to terminate ---> SunFDDI/P 1.0 Adapter User’s Guide—May 1997 # /opt/SUNWconn/bin/pf_install_agents SMT Request Frame (SRF) trap reports from the local station. You can send SRF trap reports to more than one console. Each console must...
Page 47
4. Specify the destination directory for the SunFDDI/P schemas. SunNet Manager looks for the schemas in the directory <basedir>/SUNWconn/snm/agents. The variable <basedir> is set to /opt by default. If you installed the SunNet Manager agents and libraries on the FDDI station, or if you used getagents to recover the agents from the console, then this directory exists.
3. Modify the /etc/hosts file to remove the IP addresses and host names 4. Reboot the machine to ensure correct system operation. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 The post-remove script removes the modifications made to the system files and updates the package information on your machine.
Improving Network Performance High Performance FDDI Networks Ring Latency Improvement Data Throughput Improvement Performance Across Bridges Target Token Rotation Time (TTRT) Improving Performance This chapter tells you how to optimize your FDDI network and assumes that you are familiar with FDDI network architecture and related terminology. See Chapter 6, “FDDI Network Architecture”...
FDDI stations. However, these modifications are rarely practical in an established network. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Throughput is a measure of the ring use. Network efficiency is defined as the ratio of actual throughput to theoretical maximum bandwidth (100 Mbps).
Data Throughput Improvement The most significant improvements in throughput are achieved by maximizing the rate at which data is transferred to and from the FDDI network. If you are running TCP/IP or UDP/IP applications, you can improve throughput by modifying the parameters that control the rate at which these protocols transfer data to and from the SunFDDI/P device driver—that is, between user space and kernel space.
Setting the value of T_req on a single station does not guarantee that this bid will win the claim process. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 If the network load is very irregular (bursty traffic), the TTRT should be set as high as possible to avoid lengthy queueing at any one station.
Improving Performance The following section describes how to modify the user-configurable network parameters. To obtain optimum network performance, you may need to tune these parameters, depending on your network configuration and the type of network traffic. Changing the High and Low Water Marks The maximum rate at which data is transferred between user space and kernel space by applications that use STREAMS is controlled by the high water marks.
Use ndd(1M) to change the TCP and UDP low water marks: 1. Log in as root or become superuser. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 (tcp_xmit_hiwat and tcp_recv_hiwat). For optimum performance over FDDI connections, the TCP high water marks should both be set to 32 Kbytes.
2. Use ndd —set to modify the current value of the TCP and UDP low water marks (tcp_xmit_lowat and udp_xmit_lowat). For optimum performance over FDDI connections, set the TCP and UDP low water marks to 24 Kbytes. # ndd —set /dev/tcp tcp_xmit_lowat 24576 # ndd —set /dev/udp udp_xmit_lowat 24576 Tuning the High and Low Water Marks at Boot Time Each time you reboot your machine, the high and low water marks are reset to...
3. Reboot the machine to apply the changes to the system. Note – Additionally, the ifconfig(1M) command can be used to change the MTU. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 set pf:pf_mtu=<packet_size> The variable <packet_size> is set to the desired value for MTU entered in octets.
To Disable MTU Path Discovery Many bridges do not support MTU path discovery. To disable this feature in order to transmit packets across a bridge, type: # ndd —set /dev/ip ip_path_mtu_discovery 0 MTU path discovery is re-enabled each time the machine is rebooted. To Tune the Target Token Rotation Time (TTRT) The target token rotation time (TTRT) for the network is the lowest value of T_req bid during the claim process.
Troubleshooting and Diagnostics Troubleshooting Checklist Solving Common Problems Running the Hardware Self-Test Program Loading the Device Driver Manually This chapter describes how to detect and resolve common problems with your FDDI network. It includes instructions on how to load and configure the SunFDDI/P device driver manually, if required.
• • To Check the Link Status Indicator • SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Check that the cable connector is seated firmly into the plug on the SunFDDI/P adapter card. You should feel the connector “click” into place. Check that the cables are connected correctly between ports of different types.
• If the LED is amber, the SunFDDI/P driver is loaded, the pf interface is configured, but no valid line state to an active FDDI network exists. a. Check the physical connections between the station and the ring, or the station and the concentrator. b.
NIS map, or in /etc/hosts on the local machine if you are not using NIS/NIS+. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Use netstat(1M) to check that the SunFDDI/P (pf) driver is installed correctly, and to check for an excessive number of errors and collisions:...
To Check the IP Routing 1. Check the IP routing table using the netstat(1M) command: % netstat —nr 2. Check that the FDDI subnetwork is featured in the routing table. If the routing table is empty, check that the routing daemon (in.routed) is running on your machine.
SMT frames. If the target station receives an SMT request for an unsupported service, it issues a Request Denied Frame (RDF). SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Use netstat(1M) to check the driver statistics: # netstat -k...
Two or more interfaces have been assigned the same MAC address. The most likely conflict lies between the first SunFDDI/P 1.0 interface (pf0) and one or more SunFDDI/P interfaces (pf1, etc) installed in the same machine.
Page 66
Running pf_stat without the —m option (to display information about the local station) shows the ring alternating frequently between UP and DOWN. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Problems Running SunFDDI/P Action Check that the SunFDDI/P software is installed correctly and that the driver is loaded and configured.
Page 67
Table 5-2 Problem Running pf_stat without the —m option (to display information about the local station) shows that the ring is ISOLATED. The local station cannot reach FDDI stations located on a remote FDDI network. Troubleshooting and Diagnostics Problems Running SunFDDI/P (Continued) Action Check that the link status indicator is green, indicating that the SunFDDI/P interface is attached to an active network.
Page 68
Running pf_stat with the —m option (to display information about the neighboring stations) shows frequent error frames and lost frames. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Problems Running SunFDDI/P (Continued) Action Check that the IP address and host name of the remote station is entered in the NIS map or NIS+ tables (or in /etc/hosts on each remote station if you are not running NIS or NIS+).
Table 5-2 Problem Running pf_smtmon shows the frequent occurrence of request denied frames (RDF). Table 5-3 Problem Cannot select pf_fddi or pf_fddismt7_2 agent for quick dump. Cannot recover SMT statistics from the proxy agent. The procedure fails with the error message, “Cannot create RPC client: program is not registered.”...
To Run the Hardware Self-Test 1. Log in as root or become superuser. 2. Halt the machine. 3. At the boot prompt, type: SunFDDI/P 1.0 Adapter User’s Guide—May 1997 # sync;sync;halt ok test /pci/pf Local MAC Address 0:80:d8:10:3:ed (Canonical) Interrupt register read/write test ... PASS CMT Processor read/write test ...
Loading the Device Driver Manually Normally, the SunFDDI/P device driver is loaded and configured by the post-installation script, which is launched automatically when the software is installed. If you encounter problems when running this script, or if you want to customize the installation, you may need to load the device driver manually. To Configure and Load the Device Driver 1.
Page 72
Provided the installation and configuration was successful, your SunFDDI/P station is now active and you can send and receive data transparently across an FDDI connection. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 b. Look in the /dev directory for links to these entries: ls -l /dev | grep pf lrwxrwxrwx 1 root other <date>...
FDDI Network Architecture FDDI Network Model FDDI Network Architecture FDDI Failure Recovery FDDI Ring Operation FDDI Performance This chapter provides a brief introduction to the Fiber Distributed Data Interface (FDDI), and the network architecture described by the following specifications: • ANSI/FDDI Physical Media Dependent (PMD) X3.166-1990 •...
• Figure 6-1 shows the organization of these components, and their relationship with other network protocols that use them. Figure 6-1 SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Physical Medium Dependent (PMD) Layer Physical (PHY) Layer Medium Access Control (MAC) Layer...
Physical Medium Dependent (PMD) Layer This portion of the FDDI network model defines the physical medium used to carry the encoded digital signal. It is also referred to as the media layer. The PMD layer determines the characteristics of the transmitters, receivers, connectors, and cables used to attach the FDDI station to the network.
Station Management (SMT) Layer The Station Management layer provides services to manage, control, and configure the FDDI network. It is also referred to as the network management layer. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Synchronous (guaranteed) traffic Asynchronous (priority-based) traffic Restricted (dialogue-based) traffic...
At its lowest level, the SMT protocol handles connection management (CMT). This includes station initialization, the insertion and removal of stations on the network, and connection compatibility between stations. At a higher level, the SMT protocol handles ring management (RMT). This includes the detection of duplicate addresses and the isolation of fault conditions.
Media access control (MAC) layer Frames Physical (PHY) layer Symbols Physical medium dependent (PMD) layer Bit stream Figure 6-2 Communication Between FDDI Layers SunFDDI/P 1.0 Adapter User’s Guide—May 1997...
FDDI Network Architecture A typical FDDI network is based on a dual, counter-rotating ring, as illustrated in Figure 6-3. Each FDDI station is connected in sequence to two rings simultaneously—a primary ring and a secondary ring. Data flows in one direction on the primary ring, and in the other direction on the secondary ring.
Pout to a downstream station, as shown in Figure 6-4. Single-attached stations are normally attached to single- and dual-attached concentrators, as described in “FDDI Concentrators” on page 58. Data to downstream station Figure 6-4 SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Single-attached station (SAS) Dual-attached station (DAS) Single-attached station (SAS)
Dual-Attached Station (DAS) A dual-attached station (DAS) is attached to the FDDI network through two connectors called the A-port and the B-port, respectively. The A-port has a primary input (Pin) and a secondary output (Sout); the B-port has a primary output (Pout) and a secondary input (Sin).
S-port on a single-attached station. It has multiple M-ports, to which single-attached stations are connected, as shown in Figure 6-6. Single-attached station Data to downstream station Figure 6-6 SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Single-attached concentrator (SAC) Dual-attached concentrator (DAC) Single-attached station (SAS) (SAS)
Dual-Attached Concentrator (DAC) A dual-attached concentrator (DAC) is attached to the FDDI network through two ports—the A-port and the B-port, which are identical to the ports on a dual-attached station. It has multiple M-ports, to which single-attached stations are connected, as shown in Figure 6-7. Dual-attached concentrators and FDDI stations are often arranged in a very flexible network topology called the ring of trees.
In this condition, the primary and secondary rings are wrapped on to each other to form a single, one-way ring. FDDI DAS Figure 6-8 SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Failed FDDI DAS FDDI DAS Isolating a Single Station Failure FDDI DAS...
This failure recovery mechanism is only supported by dual-attached stations and concentrators; a single-attached station connected directly to the ring cannot wrap around the fault because it is only connected to one ring at a time. The effect of a cable or link failure on a basic FDDI network is very similar to a station failure, as shown in Figure 6-9.
The attenuation in an optical bypass switch is far greater than in a normal FDDI connection; therefore, the number of optical bypass switches that can be connected in series in a single ring is limited. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Dual-attached station (DAS)
FDDI DAS FDDI DAS Figure 6-11 Dua-Ring Network Divided by Two Faults The maximum number of active optical bypass switches that can be connected in a series is four. This assumes that the maximum distance between stations in the ring is no more than 400m; otherwise, the aggregate attenuation in the ring exceeds the total optical power budget.
FDDI Ring Operation Two types of traffic are allocated bandwidth on an FDDI ring: • Unrestricted Asynchronous Transmission The FDDI network is most commonly used for unrestricted asynchronous traffic. This is the default mode for SunFDDI and is the only mode supported in a Solaris 1.x environment.
Ethernet connections. Among the factors that affect FDDI network performance are: • SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Token Rotation Timer (TRT) The TRT measures the time between successive arrivals of the token or, the time taken for the token to rotate once around the ring.
Page 93
• Network load • Network efficiency • Processor speed (on the FDDI stations) • Bus architecture There are a number of ways of improving the overall performance of the network, some of which are discussed in Chapter 4, “Improving Network Performance.”...
FDDI Network Topologies Basic Dual-Ring Network Standalone Concentrator Concentrators with Dual-Homing Tree of Concentrators Ring of Trees Mixed FDDI/Ethernet Networks FDDI networks can be arranged in a variety of ways, depending on the placement of stations (SAS and DAS) and the use of concentrators (SAC and DAC).
The primary advantages of the dual-ring network topology are its simplicity and its ability to recover from simple station and line faults. The secondary ring provides an effective backup in the event of a single failure in the ring. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 FDDI DAS FDDI DAS...
When a ring fails, the primary ring is wrapped automatically on either side of the fault so that the primary and secondary rings are combined to form a single, one-way ring. This mechanism is described in more detail in “FDDI Failure Recovery”...
Concentrators are inherently more stable than FDDI stations. They do not have monitors, or disk drives, are subject to more predictable SunFDDI/P 1.0 Adapter User’s Guide—May 1997 FDDI SAS FDDI SAS...
usage, and are less likely to be switched off. As a result, a standalone concentrator provides a more reliable network than the basic dual-ring configuration described on page 70. Concentrators are equipped with built-in electrical bypass facilities that isolate single-station faults. Unlike the station optical bypass facility described on page 62, there is no limit to the number of stations that can be bypassed using the electrical switches in concentrators.
SunFDDI 2.0. In the RSAS configuration, two single-attached interfaces are used to emulate a dual-attached interface connected in a dual-homing configuration. RSAS is not supported by SunFDDI/P 1.0. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 A-port M-port M-port...
Advantages Dual-homing offers the same advantages as a standalone concentrator, described on page 72. It also offers improved resistance against cable faults and concentrator failure. Disadvantages The number of stations that can be attached to the concentrator is limited by the number of M-ports, which is typically between 2 and 32.
The cumulative length of the network is increased significantly because the limitation on distance occurs between the end-station and the nearest concentrator, and not between the end-station and the root concentrator. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 FDDI SAS FDDI SAS...
Disadvantages This configuration suffers from the same disadvantages as the standalone concentrator, described on page 72. The number of stations connected to each concentrator is limited by the number of M-ports, and the loss of a concentrator takes down all of the stations to which it is attached. Ring of Trees The ring of trees is a derivative of the tree of concentrators topology described on page 75.
The cumulative length of the network can be increased because the limitation on distance occurs between the end-station and the nearest concentrator, and not between the end-station and the root concentrator. Disadvantages Only the concentrators attached directly to the dual-ring benefit from its inherent redundancy. SunFDDI/P 1.0 Adapter User’s Guide—May 1997...
Mixed FDDI/Ethernet Networks This section concentrates on the implementation of mixed FDDI/Ethernet networks. The same principles could be applied to mixed FDDI/802.3 and mixed FDDI/802.5 (Token Ring) networks. FDDI and Token Ring networks are based on a ring topology; Ethernet and 802.3 networks are based on a bus topology.
A tree of concentrators of the type described on page 77 is attached to an Ethernet network by connecting your system to the root concentrator as shown in Figure 7-8 Figure 7-8 SunFDDI/P 1.0 Adapter User’s Guide—May 1997 FDDI network Basic Mixed FDDI/Ethernet Topology Ethernet...
A Ring of Trees in an Ethernet Network A ring of trees of the type described on page 77 is attached to an Ethernet network by connecting your system to one of the concentrators in the main distribution frame, as shown in Figure 7-9. Ethernet FDDI/Ethernet IP router...
An identical number of hops between the two stations exists regardless of the route taken; therefore, routed may send all of the traffic across the slower Ethernet link in preference to the faster FDDI link. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 jill bob-le0...
Page 109
To avoid this situation, set up a static route that forces the traffic between jill and judy to pass over the FDDI link; however, static routing is not recommended in a network beyond a few nodes in size. For efficient IP routing in large FDDI/Ethernet networks, use a routing package that provides routing metrics in addition to hop count (for example, gated, public domain software available by the Center for Theory and Simulation in Science at Cornell...
Using the SunFDDI Network Utilities Changing the Default MAC Address (pf_macid) Displaying SunFDDI/P Statistics (pf_stat) Monitoring SMT Frames (pf_smtmon) This chapter describes the network utilities of SunFDDI/P. Throughout this chapter, it is assumed that you have installed the SunFDDI/P software under the default base directory <basedir> for your operating system: The default base directory <basedir>...
2. Use the pf_macid(1M) utility to recover the MAC address from the 3. Modify the start-up file on your machine so that the MAC address is SunFDDI/P 1.0 Adapter User’s Guide—May 1997 IDPROM on the SunFDDI/P interface identified by the instance number <inst>.
if statement to initialize interface pf<inst> --------> 4. Reboot your machine to assign the new MAC address to the SunFDDI When a SunFDDI/P card takes the host-resident MAC address, it can be swapped to another system without affecting the existing network. However, once a station starts sending packets on the network, the Address Resolution Protocol (ARP) updates the ARP tables on other stations to include the MAC address of its interface.
For example, to monitor the interface pf0 once every 60 seconds for 3 minutes (a total of 3 interrogations), type: SunFDDI/P 1.0 Adapter User’s Guide—May 1997 The ECM heading corresponds to the 5.1 MIM heading. The RMT heading does not have an analog in SMT revision 4.2. If you run SunFDDI/P at revision level 4.2, ignore any data displayed under the RMT...
Page 115
Interpreting Local Statistics Running the pf_stat utility without the —m option displays information about the various SMT state machines and the network to which the local station is attached: Ring (Ring Status) The Ring status shows the current state of the physical connection to the FDDI network.
State ISOLATED NON_OP RING_OP DETECT SunFDDI/P 1.0 Adapter User’s Guide—May 1997 pf_stat States Under the ECM Heading Meaning ECM is inactive and is waiting for a connect request (initial state). ECM is active; normal state after successful connection request. ECM is propagating a trace request to the appropriate entity.
Table 8-2 pf_stat States Under the RMT Heading (Continued) RMT has detected that its address is duplicated and is initiating NON_OP_DUP recovery. The ring is not operational in this state. RMT has detected that the MAC address is duplicated and flagged RING_OP_DUP the error.
Running pf_stat with an interval and count, displays the number of packets transmitted since the last interrogation. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 pf_stat States Under the PCM Heading (Continued) Second state in the sequence leading to a synchronized connection.
RecvP (Receive Packets) Running pf_stat without an interval and count displays the total number of packets received since the interface was activated. Running pf_stat with an interval and count displays the number of packets received since the last interrogation. Example Local Statistics The following output was recovered from a single-attached station using the command shown.
For example, to monitor the stations attached to pf0 once every 10 seconds for 1 minute (a total of 6 interrogations), type: SunFDDI/P 1.0 Adapter User’s Guide—May 1997 The minimum interval of one second is not fast enough to recover and display the complete sequence of PCM states during the path re-establishment phase.
Page 121
Interpreting Statistics from Neighboring Stations Running the pf_stat utility with the —m option displays information about the neighboring stations attached to the local interface pf<inst>. Phy (Physical Connection) PHY shows the type of physical connection to the FDDI network. This heading is modified to indicate the type of port being managed: •...
Page 122
Displays the MAC address for the neighboring station, connected upstream on the ring from the local station. DNA (Downstream Neighbor Address) Displays the MAC address for the neighboring station, connected downstream on the ring from the local station. SunFDDI/P 1.0 Adapter User’s Guide—May 1997...
Page 123
Example Neighbor Statistics The following output was recovered from a single-attached station using the command shown. A temporary fault condition was simulated by disconnecting the FDDI cable from the SunFDDI/P card and then reconnecting it. Start pf_stat ----------> # <basedir>/pf_stat —m pf0 1 20 PhyS Accumulated statistics ->...
Use Ctrl-C to stop pf_smtmon. To display the encoded SMT frames received by interface pf1, type: The elements of the SMT frames are defined as follows: class_type SunFDDI/P 1.0 Adapter User’s Guide—May 1997 <inst> # <basedir>/pf_smtmon # <basedir>/pf_smtmon -i pf1...
(such as the SunNet Manager proxy agent delivered with SunFDDI/P) receives an unsupported or unrecognized request, it issues an RDF frame to indicate that the request is rejected. An RDF frame is always a response. SunFDDI/P 1.0 Adapter User’s Guide—May 1997...
ESF (Extended Service Frame) These frames are implementation dependent. An ESF frame can be an announcement, a request, or a response. PMF (Parameter Management Frame) These frames are used to access remote station attributes. The Parameter Management Protocol supports both get (display) and set (modify) functions; however, the pf_smtmon utility can display only PMF_get frames.
Managing FDDI Stations Using SunNet Manager Installing the SunNet Manager Agents Managing FDDI Networks with SunNet Manager This chapter describes how to configure and start the SunNet Manager agents for SunFDDI/P on your machine. It also tells you how to use a SunNet Manager console to recover FDDI statistics from the agents.
There are two ways to install the SunNet Manager agents on the client machine: Both methods are described in the SunNet Manager Installation Guide. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 The SunFDDI/P local agent (pf_fddi) responds to SNM requests from the console and returns statistics gathered on the client machine. These statistics are similar to those returned by pf_stat(1M).
To Install the FDDI Schemas on a Client Use pf_install_agents to install the SunNet Manager agents for SunFDDI/P. This script copies the FDDI schema files to the directory in which the standard agents are installed and updates the configuration files for SunNet Manager.
SunFDDI/P schemas onto the console machine or NFS mount the pf_install_agents script from a client machine and execute it remotely. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 This is the base directory under which you installed the SunFDDI/P software package (SUNWpf) using pkgadd(1M).
To Share pf_install_agents From a Client 1. On the client machine, ensure that the NFS and mount daemons are running: # /usr/lib/nfs/nfs 8 # /usr/lib/nfs/mountd 2. On the client machine, share the /opt directory under which you installed SunFDDI/P. # share -F nfs -o ro /opt 3.
Page 134
Ultra system, add the following line to elements.schema: Add this line ---------> SunFDDI/P 1.0 Adapter User’s Guide—May 1997 On the console machine, the schemas must be installed in the directory /opt/SUNWconn/snm/agents. The pf_install_agents script modifies the file /opt/SUNWconn/snm/struct/elements.schema to add the definition for the host name or MAC address of an FDDI station.
Managing FDDI Networks with SunNet Manager For detailed information on how to use SunNet Manager to manage the various components of your network, refer to the SunNet Manager User’s Guide. The SunNet Manager agents for SunFDDI/P are used to recover FDDI statistics and SMT frame information.
3. Choose pf_fddi as the Agent Schema and if (interface) as the Group. 4. Click SELECT on Apply to display local station statistics similar to those Figure 9-1 SunFDDI/P 1.0 Adapter User’s Guide—May 1997 interrogate. Quick Dump item. shown in Figure 9-1.
To Gather Neighbor Station Statistics Use the SunFDDI/P local agent to recover a snapshot of the current state of the neighboring FDDI stations: 1. Click SELECT on the icon for the FDDI station that you want to interrogate. 2. Press MENU on the Requests menu button and release MENU on the Quick Dump item.
1. Specify the target machine when you enable the SunFDDI/P proxy agent 2. Use the scroll bar to display the two SunFDDI/P agents as shown in Figure 9-4 SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Proxy station RPC request SMT request...
To Gather Information from the Proxy Agent Use the SunFDDI/P proxy agent to recover SMT information from one of the neighboring FDDI stations: 1. Click SELECT on the icon for the FDDI proxy station that you want to interrogate. 2. Press MENU on the Requests menu button and release MENU on the Quick Dump item.
The trap reports in Figure 9-7 were generated when a single-attached station was reconnected to the ring. Trap report generated by the upstream station Source of trap report ------> SRF_Source=rully (neighbor to fault) TransitionTimeStamp: Parameter_Type=0x1034 Transition_TimeStamp.Hi=102 Transition_TimeStamp.Lo=845593304 Trap indicates change of neighbor ----------------->...
MAC Address Formats The MAC address can be represented in one of two formats: • Canonical format • Ring format The MAC address is always displayed in canonical format by the SunFDDI/P network utilities and hardware self-test program. It is also displayed in canonical format when you reboot your machine.
DLPI is used to access the services of the SunFDDI/P link layer of the SunFDDI/P device driver in a Solaris 2.5.1 Hardware: 4/97 environment without the need for specialized knowledge of the underlying protocol. You can obtain a copy of the STREAMS DLPI Specification from Sun Microsystems, Inc. (part number 800-6915-10).
(for example, the pf FDDI driver). Figure 10-1 illustrates the relationship between DLPI and the layers of the FDDI protocol. Figure 10-1 DLPI Access to FDDI SunFDDI/P 1.0 Adapter User’s Guide—May 1997 TCP/IP Data link provider interface (DLPI) V2...
DLPI primitives are defined in terms of STREAMS messages. All DLPI messages are either type M_PROTO or type M_PCPROTO and contain the appropriate DLPI message structure. DPLI primitives are exchanged by confirmed negotiation—request primitives are issued by the user, which then waits to receive an acknowledge (or error) response primitive from the provider.
SunFDDI/P device driver is shown in Table 10-1. Table 10-1 DL_INFO_REQ Frame Element dl_max_sdu dl_min_sdu dl_addr_length dl_mac_type dl_reserved dl_current_state dl_sap_length dl_service_mode dl_qos_length SunFDDI/P 1.0 Adapter User’s Guide—May 1997 6 Bytes 2 Bytes SSAP CTL TYPE SNAP Value 4352 bytes 0 bytes 8 bytes DL_FDDI —...
Page 149
Table 10-1 DL_INFO_REQ Frame Element Value dl_qos_offset dl_range_length dl_range_offset dl_provider_style DL_STYLE2 dl_addr_offset dl_version dl_brdcst_addr_length dl_brdcst_addr_offset Note that the value dl_sap_length is set to minus 2, which indicates that the SAP is 2 bytes beyond the physical address. Developing Applications that Run over SunFDDI/P Description Not supported Not supported...
Setting Up Servers and Diskless Clients Setting Up a Server and Diskless Clients Booting a Diskless Client Over SunFDDI/P This chapter describes how to set up a server so that you can boot and run diskless clients across an FDDI network. It assumes that the server and clients are attached to the same FDDI ring.
If you have five Sun-4u diskless clients running Solaris 2.5.1 Hardware: 4/97, you will require: • • • SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Use df(1M) to check the amount of space available, for example, type: % /usr/bin/df -k /export Filesystem kbytes...
To Set Up a Server Follow these steps to set up a server to boot diskless clients across an FDDI connection: 1. Install and configure the relevant SunOS operating system on the server so that it can be exported. See the Solaris System Configuration and Installation Guide for detailed instructions on how to set up an operating system for diskless clients.
Page 154
3. Click SELECT on the Host Manager icon to display the Select Naming 4. Click SELECT on the button corresponding to the naming service used by SunFDDI/P 1.0 Adapter User’s Guide—May 1997 Service window. the server to display list of available hosts.
Page 155
5. Click SELECT on Apply to display the Host Manager window. 6. Press MENU on the Edit menu button and choose the Add Host... item to activate the Add Host window. Setting Up Servers and Diskless Clients...
Page 156
9. Use MENU to set the Timezone Region and Timezone that are relevant for 10. Press MENU on the File Server menu button to display a list of available SunFDDI/P 1.0 Adapter User’s Guide—May 1997 display the defaults for diskless clients.
Page 157
11. Specify the root and swap paths. By default, these paths are set to /export/root and /export/swap. If you change these paths, you must ensure that you have sufficient disk space in the file systems you specify. 12. Specify the size of the swap space reserved for the diskless client. This is normally set to 24 Mbytes.
4. Change directories to the diskless client’s root file system. 5. Update the yp map for the diskless client: 6. Replace the noname entry in the file /etc/defaultdomain with the your SunFDDI/P 1.0 Adapter User’s Guide—May 1997 the new entries created in the following files: • /etc/hosts •...
Installing the SunFDDI/P Driver for a Diskless Client After you have created the export file systems under /export/root/<client> and /export/swap/<client> on the server, you must install the SunFDDI/P device driver for the diskless client. To Install on a Client 1. Use pkgadd to install the Solaris 2.5.1 version of SunFDDI/P so that it is 2.
Page 160
5. At the prompt, type boot then press CTL-y to paste your selection. Warning – Once a diskless client has been booted over the SunFDDI/P interface, do not move the SunFDDI/P card to a different slot. SunFDDI/P 1.0 Adapter User’s Guide—May 1997 interfaces. ok show-nets...
Frequently Asked Questions About SunFDDI This appendix contains the responses to some of the most frequently asked questions about SunFDDI/P. It also contains references to more detailed information. • The network performance is much lower than I expected. Why can’t I transfer data at 100 Mbps over my FDDI connection? If the applications running over FDDI don’t use the available bandwidth efficiently you will see much lower performance than expected.
Page 162
See “Concentrators with Dual-Homing” on page 74 for more information. Can I use the SunFDDI/P 1.0 software with a hardware interface from a third-party vendor? No. The device driver does not support any third-party hardware products.
Page 163
• Why do I get the error message “duplicate address” or “duplicate macid”? By default, the first SunFDDI/P interface installed in the machine adopts the host-resident MAC address stored on the motherboard. Each subsequent SunFDDI/P interface takes the card-resident MAC address stored in its IDPROM.
Page 164
How many SunFDDI/P 1.0 cards can I install in one machine? You can install up to eight SunFDDI/P 1.0 cards in one machine. What kind of connector can be used to connect SunFDDI/P 1.0 to optical fiber networks? The connector type has been changed for SunFDDI 5.0 to an SC-type connector.
Page 165
• Does SunFDDI/P Dual incorporate an optical bypass? No. You must order an optical bypass switch from a third-party vendor. • Why does my optical bypass switch not work when I plug it in? Optical bypass switches require a power cycle to be initialized. Plug in the optical bypass switch, switch off the FDDI station, and then reboot to initialize the station.
Page 167
baud Glossary This glossary defines FDDI-related acronyms, abbreviations, and terms. (Address Resolution Protocol). A protocol used within local networks that support broadcast (such as Ethernet or FDDI) that binds IP addresses to MAC addresses. View the current contents of a Sun machine’s ARP table with the SunOS command, arp -a;...
Page 168
In general usage, the term identifies any computer that transfers information between networks. (kilobits per second). A measure of the rate of data transmission. See also, baud, bps, Bps, and Mbps. SunFDDI/P 1.0 Adapter User’s Guide—May 1997...
Page 169
Mbps NRZI-4B/5B (Logical Link Control). Local area network protocol functions corresponding to the OSI data link layer (layer 2), but providing only service access points (SAP). (Media Access Control). Local area network protocol functions corresponding to the OSI data link layer (layer 2), but providing the following: 1) on transmission, assembles data into a frame with address and error-detection fields;...
Page 170
The deviation of clock recovery that can occur when the receiver attempts to recover both clocking and data from the received signal. The PHY specification describes a phase lock loop (PLL) and elasticity buffer to eliminate jitter. SunFDDI/P 1.0 Adapter User’s Guide—May 1997...
Page 171
TTRT (Token Rotation Timer). A timer in the FDDI MAC protocol that measures the time between receipt of tokens. It expires when it reaches a value that exceeds the Target Token Rotation Time (TTRT). (Target Token Rotation Time). A parameter in the FDDI MAC protocol that is negotiated by all of the stations on a ring at the time a ring is brought up.
Page 176
