INTRODUCTION
STM32-H107 header board provides easy way for developing and prototyping with
the
STMicroelectronics. STM32-H107 has JTAG port for programming and debugging,
USB_OTG, user button, two status leds, and most of the GPIOs are on extension
headers where you can connect your additional circuits.

BOARD FEATURES

-
-
-
-
-
-
-
-
-
-
-
-
-

ELECTROSTATIC WARNING

The STM32-H107 board is shipped in protective anti-static packaging. The board
must not be subject to high electrostatic potentials. General practice for working
with static sensitive devices should be applied when working with this board.

BOARD USE REQUIREMENTS

Cables: The cable you will need depends on the programmer/debugger you use. If
you use ARM-JTAG, you will need LPT cable, if you use ARM-USB-OCD, you will
need RS232 cable and 1.8 meter USB A-B cable and if you use ARM-JTAG-EW, you
will need 1.8 meter USB A-B cable.
Hardware: Programmer/Debugger – one of the Olimex ARM Programmers: ARM-
JTAG, ARM-USB-OCD, ARM-JTAG-EW.
Software: ARM C compiler and JTAG programmer.
Note: For OpenOCD we don't offer any projects.

PROCESSOR FEATURES

new STM32F107
CPU: STM32F107 32 bit ARM-based microcontroller with 256 KB Flash, 64KB
RAM, USB OTG, Ethernet, 10 timers, 2 CANs, 2 ADCs, 14 communication
interfaces
JTAG connector with ARM 2x10 pin layout for programming/debugging
25 Mhz crystal
USB_OTG
Power Jack
WKUP button
RESET button
Two status leds
Power-on led
3V battery connector
Extension port connectors for many of microcontrollers pins
PCB: FR-4, 1.5 mm (0,062"), soldermask, silkscreen component print
Dimensions: 70x50mm (2.76x1.97")
connectivity line
