INTRODUCTION
MOD-ZIGBEE features a bundle of 8bit PIC18 processor and an 802.15.4
compatible radio module that makes it easy to develop applications based on RF
communication and especially ZigBee based protocol stacks. In addition MOD-
ZIGBEE implements an on-board digital temperature sensor, for remote
temperature reporting.
BOARD FEATURES
ELECTROSTATIC WARNING
The MOD-ZIGBEE board is shipped in protective anti-static packaging. The board
must not be subject to high electrostatic potentials. General practice for working
with static sensitive devices should be applied when working with this board.
BOARD USE REQUIREMENTS
Cables:
Hardware:
Software:
•
CPU: PIC18F26K20
•
RF Transceiver – MRF24J40 IEEE 802.15.4™ standard compliant 2.4
GHz RF transceiver
•
ICSP connector
•
On-board antenna
•
On-board temperature sensor – TCN75A
•
Option for external power supply through EXT_PWR
•
EXT/BAT switch
•
Reset circuit
•
two user buttons
•
two status LEDs
•
RST button
•
+3V lithium battery holder
•
PCB: FR-4, 1.00 mm (0,039"), solder mask, silkscreen component print
•
Dimensions: 65.15x20.38 mm (2.56x0.80")
The cable you will need depends on the programmer/debugger you
use. If you use PIC-ICD2-POCKET or PIC-Kit3 you will need 1.8 m A-
B USB cable.
One of Olimex programmers/debuggers – PIC-ICD2-POCKET, PIC-
KIT3, or other compatible programming/debugging tool. Also
note that you would need adapter for the small ICSP connector (0.05''
step) - PIC-ICSP
MPLAB IDE
