OLIMEX STM32-H107 User Manual page 11

11
13
15
17
19
PWR_JACK:
Pin #
1
2
USB_OTG
Pin #
1
2
3
4
5
3V_BAT
Pin #
1
2
PULL-DOWN
TDO
RST
PULL-DOWN
+5V_JTAG
Signal Name
Power Input
GND
Signal Name
+5V_OTG_PWR
USB_OTG_D-
USB_OTG_D+
OTG_ID
GND
Signal Name
VBAT
GND
12 GND
14 GND
16 GND
18 GND
20 GND
Page11
