3. Confirm that the XSCF STANDBY LED (green) on the operator panel is lit.
4. Push the power switch on the operator panel to power on the server.
The server starts and begins a self-diagnosis.
Watch the initial system administration console for error messages during the boot
process. See
5. Confirm that "ok" is displayed on the domain console.
6. Confirm that the POWER LED (green) on the operator panel is lit.
7. Check the POWER LED on each component.
If the POWER LEDs are not lit see
information.
8. Press and hold the Enter key, and press the "#." (shift-3 and period) keys.
These key combinations switch you from the domain console to the XSCF console.
9. Execute fmdump or showlogs with the error option from the XSCF Shell and
confirm that no errors are found.
See the
Command" on page B-5
10. Connect the system control network to the XSCF Unit LAN port using an Ethernet
cable.
The system control network is one or more administrative consoles used to monitor
the network. This connection will replace the temporary connection made between
the administration console and the serial port on the XSCF Unit. Both XSCF Unit
LAN ports must be used to ensure redundancy in the system control network.
Note – The XSCF Ethernet port is IEEE 802.3i and IEEE 802.3u compliant. This
requires auto-negotiation for the port into which it terminates.
3.4.1

Verifying the Configuration

Verify the hardware configuration by following the procedure below on a console
connected to the system control network.
1. Log in to the server and access the XSCF Shell.
Refer to the SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers XSCF
User's Guide for details.
Appendix B for fault installation information.
"Using the fmdump Command" on page B-6
for details.
Appendix B for installation troubleshooting
and
Chapter 3 Installing the Server
"Using the showlogs
3-9
