Key Features
Connection Pads
01
TFT 320x240 display
02
USB MINI-B connector
03
Charge indication LED
04
LI-Polymer battery connector
05
3.5mm headphone connector
06
Power supply regulator
07
Crystal oscillator
08
VS1053 Stereo mp3 coder/decoder
09
RESET button
10
STM32F207VGT6 or STM32F407VGT6
11
microcontroller
Accelerometer
12
Serial Flash memory
13
microSD Card Slot
14
Power indication LED
15
JTAG/SWD programmer connector
16
01
02
