8. Audio Module
Figure 8-2:
Inserting 3.5mm
headphones jack
Figure 8-1:
On-board VS1053
MP3 codec
The mikromedia for STM32® features stereo audio codec VS1053. This module
enables audio reproduction by using stereo headphones connected to the
system via a
3.5mm
connector CN2. All functions of this module are controlled
by the microcontroller over Serial Peripheral Interface (SPI).
Page 28
