4. Reset Buttons

Board is equipped with two reset buttons. First is located at the back side of the
board (Figure 4-1), and second one is at the top of the front side (Figure 4-2).
If you want to reset the circuit, press either of two buttons. It will generate low
voltage level on microcontroller reset pin (input). In addition,
a reset can be externally provided through pin 27 on
side headers (Figure 4-3).
Figure 4-1: Reset button located at the backside of the board
NOTE: Do not press the reset buttons
during programming
Figure 4-2: Frontal reset button
