7A
INSTALLATION OF BASE (MOBILE STAND)
1.
Open the Center Support assembly box
as shown in Fig. 1.
2.
Remove the tool kit and foam sheets as
shown in Fig. 2.
3.
Lift up the Center Support assembly as
shown in Fig. 3.
4.
Place the Center Support assembly on
the floor as shown in Fig. 4.
5.
Open one of the Wheel Support
assembly boxes as shown in Fig. 5.
6.
Remove foam sheets as shown in Fig. 6.
12
Prima ENT/DNT
Fig 1
Fig 2
Fig 3
Fig 4
Fig 5
Fig 6
