FLOOR MOUNT
1. The following accessories are provided
- DSLR camera adapter for Nikon, Canon, and Sony cameras
- Adapter for Mintron CCD camera
- Adapter for Sony Handy-Cam
- Assistoscope for assistant viewing
2. Attach the accessory to the left or right side of the beam splitter.
3. DBS A beam splitter is inserted between magnichanger and observation head. Light is
divided into two beams. It can be 50:50 or 80:20. In case of 80:20 ratio, 80% of light
goes to observation head and 20% light goes to camera accessories.
4. Double Iris attachment An adjustable diaphragm attachment installed between
magnichanger and observation head /DBS/DBSi. It reduces incoming light and
increased depth of field, it is very useful for photography.
CMO 250
CMO 350
CMO 400
CCD CAMERA
ADAPTER
FOOT CONTROL Z AXIS
Fig 18
Prima ENT/DNT
Part No.: 6137000-000
Model: Prima ENT
STRAIGHT
BINOCULAR TUBE
DBS
DOUBLE IRIS
ASSISTOSCOPE
SONY HANDYCAM
DSLR CAMERA
ADAPTER
ADAPTER
23
