Prima ENT
24
3
2
1.
Wheel with brake
2.
H shape base
3.
Column
4.
Swivel arm
5.
Suspension arm
6.
Swivel arm locking knob
7.
Suspension arm movement locking knob
8.
Coupling movement locking knob
9.
Inclined coupling
10.
Inclined coupling movement knob
11.
Suspension arm hydraulic movement lock 24.
12.
Suspension arm spring tension adjustment 25.
13.
Swivel arm covers
6
4
13
7
23
6
12
1
11
5
19
22
8
9
26
10
18
16
21
17
14.
Binocular head
15.
Magnification changer
16.
Handles
17.
Common main objective (CMO)
18.
Magnichanger inclination movement lock
19.
Illumination control knob
20.
Foot pedal for Z-axis (optional)
21.
Fine focusing knob
22.
iVu Camera inlet
23.
On/Off switch
Power inlet
Eyepieces
26.
Counter balancing knob
Prima ENT/DNT
25
14
15
20
