Power Supply
The evaluation kit provides multiple input
wall adapter which plugs into barrel connector J4. In addition to powering from the wall
adapter, the evaluation kit can be powered from a standard PC USB Host port by
connecting a USB cable between the PC and J9. If powered via USB, the unit must be
configured for USB device mode (JP3 pins 1 to 2, JP5 out, JP6 out).
Power Options
Input Power Option
5V Wall Cube
USB (device mode,
power input)
LEDs
The xPico evaluation kit includes several LEDs to communicate module, Ethernet activity,
or power status. The
LED Signals
J7 LED Ref
Pin Design
6 LED1
None LED2
None LED3
Connect 5V wall cube to the J4 barrel connector.
Connect J9 USB power to a PC USB Host Port.
Note: For J9 Note unit must be configured for USB device mode
(JP3 pins 1 to 2, JP5 out, JP6 out.)
LED Signals table lists all LEDs and their functions.
Color
xPico 200 Status
LED blinks with patterns indicating module status. See the
Orange
xPico 200 Series Embedded Wi-Fi Gateway User Guide
a full description of the status LED blink patterns.
Ethernet Link Status
Orange
LED is ON when there is a valid Ethernet link at 100 Mbps
Ethernet Activity
Orange
LED blinks when there is activity on the Ethernet port
Power Options. Included with the kit is a 5V
Description
LED Function
for
