Lantronix xPico 200 Series User Manual page 9

J7 module J2 Header
pin
62 26
22 27
34 28
32 29
36 30
23, 25, 31,
32
Please refer to the
evaluation board schematics.
Buttons
Button Signal
SW1 EXT_RESET#
SW2 DEFAULTS
Signal
Pin
CP10
TXD1
RTS1
RXD1
CTS1
No
connect
xPico 200 Series Embedded Wi-Fi Gateway Integration Guide
J7
Module
pin
52
23
Function
Configurable pin
10
UART transmit
data output
UART ready to
send output
UART receive data
input
UART clear to
send input
Reserved-Do not
connect
Button Function
Module Hardware Reset
Button assertion reboots the module
Module Reset to Defaults
Assert for 6 seconds upon boot up to reset the xPico
Secondary
Function
PWM Output
for
