Lantronix xPico 200 Series User Manual page 7

J7 LED Ref
Pin Design
None LED4
J2 Header Pins
The J2 Pin Header table
headers. Included is the J7 connection to the xPico 200 edge module connector.
J2 Pin Header
J7 module J2 Header
pin
N/A 2,4,6
1,7,18,33,
1,3,5,33,
9,45,51,57,
35,37,39
63,69,75
2,4,72,74 34,36,38,40
50 7
48 9
46 11
Color
3.3V Power LED
Blue
LED is ON when evaluation board 3.3V power is up.
lists the pin functionality of the additional evaluation kit
Signal
Pin
VIN
Ground
3V3(M)
CP1
CP2/INT
CP3
LED Function
Function
Evaluation board
5V power
Evaluation board
Ground
Evaluaton board
3.3V power
Configurable pin 1
Configurable pin 2
Configurable pin 3
Secondary
Function
Routes to J7 module
pins via R1
USB host mode over-
current flag input
SPI interrupt input
USB host mode port
power enable output
SPI-MISO
