Ethernet Port

The xPico 110 evaluation kit includes one RJ45 connector with on-board magnetics for
connection to the xPico 110 module 10/100Mbps Ethernet interface. Connector J2 is the
Ethernet port.

Power Supply

The evaluation kit provides several options for input power. Included with the kit is a 5V wall
adapter. The 5V wall adapter plugs into USB connector J5. In addition to powering from the
wall adapter, the evaluation kit can be powered from a standard PC USB Host port by
connecting a USB cable between the PC and J5. The evaluation kit can also be powered via
Power-Over-Ethernet (PoE). The integrated PoE regulator accepts power from the Ethernet
port on J2. The final option is to connect DC power to header JP19.
Input Power Option
5V Wall Cube
USB
PoE
JP19
xPico® 110 Wired Device Server Module Evaluation Kit User Guide

Table 2-9 Evaluation Kit Power Options

Description
Connect 5V wall cube to the J5 USB port.
Note: USB-to-serial and USB device port not available in this option.
Connect J5 USB power to a PC USB Host Port.
Note: For J5 connection, PC Host port can communicate with serial port 2 via
on-board USB-to-serial converter. See
selection.
Connect J2 Ethernet port to external PoE PSE switch or PoE injector.
Connect a 2.2V to 5.5V DC power source to JP19 pin 1 (+). Connect the
power supply DC ground to JP19 pin 2 (-).
