Mounting the Unit

Once the mounting considerations in this chapter have been met, mount the 1510 ac-
cording to the following instructions.
1. Locate a position for your 1510 that meets the specifications required (see previous
sections in this chapter and Appendix A).
2. Refer to the Mounting Dimensions (figure 3.5 or 3.6) as a guide for mounting your
system.
3. Mount and secure the 1510 unit, if required, using the mounting brackets. Refer to
the section titled Securing the Mounting Brackets for information about attaching
mounting brackets to the 1510.
4. Attach one end of the power cord to the power receptacle and the other end to a
properly grounded 115/230 VAC outlet.
5. Implement the proper grounding techniques. Establish a ground path from the 1510
chassis to the enclosure chassis. A 6-32 threaded ground point ( ) hole is provided
on the left back of the front panel (as viewed from the front) of the unit. There is also
an internal ground point ( ).
6. Turn on the power. The system will boot up to the operating system installed.
7. Install application software via a floppy drive or CD-ROM.
