Mounting Brackets and Mounting Dimensions Horizontal Mount

SHELF OR PANEL MOUNT
Figure 3-6. 1510 Mounting Dimensions for Horizontal Mount
HORIZONTAL
12.992
(329.99)
14.488
(367.99)
13.880
(352.55)
14.488
(367.99)
Chapter Three - Installation
6.763
(171.78)
6.970
(177.03)
BRACKETS
OPTIONAL FEET
(WHEN NOT USING BRACKETS)
11.142
(283.00)
12.087
(307.01)
13.036
(331.11)
15.992
(406.19)
16.060
(407.92)
