How to Set up the PIP

Enable the PIP function, the operations are as follows:
1. Push [MENU] button to enter the menu items.
2. Turn the knob and choose <OUTPUT>.
3. Push the knob to confirm, turn the knob again, choose <PIP>.
4. Push the knob to confirm, turn the knob, choose ON and confirm, then start PIP mode.
LAYOUT: Can choose PIP layout, the corresponding results are as follows:
PIP L+T PBP L+R PBP T+B
SWAP IMAGE: It can set PIP to swap exchange, when choose ON, it can realize the IMAGE A and
IMAGE B exchange.
ALPHA: Can set the image transparency, the regulating range is among 0 to 16.
SELECT: Can choose to set the size or position of IMAGE A or IMAGE B Individually.
