How to Set up the Size and Position of the Single Image

1. Push [MENU] button to enter the menu items.
2. Turn the knob, choose <OUTPUT>.
3. Push the knob to confirm, turn the knob again, choose <SCALE>.
4. Push the knob to confirm, and enter to the <SCALE> items, turn the knob, user can adjust
the following items by knob or number buttons.
5. If image quality distorts by improper operation, it can be recover by reset.
How to Set up Image Zoom
The image can be zoom in horizontal or vertical separately, to meet the special effects required.
Push the [MENU] button to go into the menu items, turn the knob and choose <INPUT>, push the knob
to confirm. Turn the knob, and choose <ZOOM>, show the menus as following:
V UP--Zoom in vertical and the image will be zoom in to the top direction from its bottom.
V DOWN--Zoom in vertical and the image will be zoom in to the down direction from its top.
V UP/DOWN--Zoom in vertical but in both top and down direction from its middle.
H LEFT--Zoom in horizontal and the image will be zoom in to the left direction from its right.
H RIGHT--Zoom in horizontal and the image will be zoom in to the right direction from its left.
H LIFT/RIGHT--Zoom in horizontal but in both left and right direction from its middle.
CENTER--Zoom in 4 corner direction from center.
RESET--If image quality distorts by improper operation, it can be recover by reset.
9
